Name: X-LAB RS7 105 12sp Singularity Black
Brand: XLab-USA
SKU: BXL9250-00017
Price: 3999.0 NZD
Availability: InStock

X-LAB RS7 105 12sp Singularity Black

SKU BXL9250-00017

$3,999.00 - $3,999.00

$3,999.00

$3,999.00 - $3,999.00

$3,999.00

Interested in this bike? Please email us or use the ENQUIRY FORM below to check your size and availability.

The bike may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY OF BIKES NATIONWIDE.

NOTE: Afterpay is unavailable on bike purchases.

Race-inspired speed, all-road performance, built for the everyday ride.

The RS7 embodies the core principles of performance road cycling: speed, responsiveness, and structural efficiency. It also happens to be a favorite among cycling enthusiasts who cannot believe its retail price.
Its carbon construction delivers race-level performance in a platform designed for riders who demand precision across training, racing, and everyday riding.

Much like its darker counterpart, the Angel Wing colorway has its roots in the French Alps and will shine as bright as any on pavement. It’s an effortlessly well-tuned ride that will stun passersby as it glides through the roads.

<div class="tech-specs">

<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">XDS Carbon Frame</p>
</div>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">XDS Carbon Fork, 100x12mm Thru-axle</p>
</div>

<div class="spec-item">
<p class="label">Seatpost</p>
<p class="value">XDS Carbon Seatpost, Aero Shape</p>
</div>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">BSA 24mm</p>
</div>
</div>

<div class="spec-section">
<h4>Drivetrain</h4>

<div class="spec-item">
<p class="label">Rear Derailleur</p>
<p class="value">Shimano 105 RD-R7100</p>
</div>

<div class="spec-item">
<p class="label">Front Derailleur</p>
<p class="value">Shimano 105 FD-R7100</p>
</div>

<div class="spec-item">
<p class="label">Shifters</p>
<p class="value">Shimano 105 ST-R7120</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">Shimano CS-R9012, 12-Speed, 11-34T</p>
</div>

<div class="spec-item">
<p class="label">Crankset</p>
<p class="value">Branta Alloy Powermeter Crankset, 52-36T, 24mm Steel Spindle</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">SUMC SX12</p>
</div>
</div>

<div class="spec-section">
<h4>Brakes</h4>

<div class="spec-item">
<p class="label">Brakes</p>
<p class="value">Shimano 105 BR-R7170</p>
</div>

<div class="spec-item">
<p class="label">Rotors</p>
<p class="value">Shimano SM-RT70, F:160mm / R:160mm</p>
</div>
</div>

<div class="spec-section">
<h4>Cockpit</h4>

<div class="spec-item">
<p class="label">Stem</p>
<p class="value">Branta Carbon Integrated</p>
</div>

<div class="spec-item">
<p class="label">Handlebar</p>
<p class="value">—</p>
</div>
</div>

<div class="spec-section">
<h4>Wheels & Tires</h4>

<div class="spec-item">
<p class="label">Wheelset</p>
<p class="value">Branta C45 Base, Steel Spokes</p>
</div>

<div class="spec-item">
<p class="label">Tires</p>
<p class="value">Branta R332, 700x32C, 60TPI</p>
</div>
</div>

<div class="spec-section">
<h4>Finishing Kit</h4>

<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">Branta R302, Steel Rails</p>
</div>
</div>

<div class="spec-section">
<h4>Additional</h4>

<div class="spec-item">
<p class="label">Weight</p>
<p class="value">8.49kg (Size L)</p>
</div>

</div>

</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col">Frame</th>
<th class="sticky-col">Size</th>
<th>XS</th>
<th>S</th>
<th>M</th>
<th>L</th>
<th>XL</th>
<th>XXL</th>
</tr>
</thead>
<tbody>


<tr>
<td class="sticky-col">A</td>
<td class="sticky-col">Seat Tube Length (mm)</td>
<td>420</td><td>440</td><td>470</td><td>490</td><td>510</td><td>530</td>
</tr>
<tr>
<td class="sticky-col">B</td>
<td class="sticky-col">Top Tube Length (mm)</td>
<td>500</td><td>515</td><td>531</td><td>550</td><td>570</td><td>590</td>
</tr>
<tr>
<td class="sticky-col">C</td>
<td class="sticky-col">Head Tube Length (mm)</td>
<td>130</td><td>135</td><td>145</td><td>160</td><td>175</td><td>200</td>
</tr>
<tr>
<td class="sticky-col">D</td>
<td class="sticky-col">Seat Tube Angle (°)</td>
<td>75</td><td>75</td><td>75</td><td>74</td><td>74</td><td>74</td>
</tr>
<tr>
<td class="sticky-col">E</td>
<td class="sticky-col">Head Tube Angle (°)</td>
<td>70</td><td>72</td><td>73</td><td>73</td><td>73</td><td>74</td>
</tr>
<tr>
<td class="sticky-col">F</td>
<td class="sticky-col">Chainstay Length (mm)</td>
<td>410</td><td>410</td><td>410</td><td>410</td><td>410</td><td>410</td>
</tr>
<tr>
<td class="sticky-col">G</td>
<td class="sticky-col">Wheelbase (mm)</td>
<td>973</td><td>976</td><td>982</td><td>993</td><td>1006</td><td>1016</td>
</tr>
<tr>
<td class="sticky-col">H</td>
<td class="sticky-col">Fork Rake/Offset (mm)</td>
<td>55</td><td>55</td><td>45</td><td>45</td><td>45</td><td>45</td>
</tr>
<tr>
<td class="sticky-col">I</td>
<td class="sticky-col">BB Drop (mm)</td>
<td>72</td><td>72</td><td>70</td><td>70</td><td>68</td><td>68</td>
</tr>
<tr>
<td class="sticky-col">J</td>
<td class="sticky-col">Stack (mm)</td>
<td>526</td><td>535</td><td>546</td><td>561</td><td>574</td><td>602</td>
</tr>
<tr>
<td class="sticky-col">K</td>
<td class="sticky-col">Reach (mm)</td>
<td>360</td><td>370</td><td>380</td><td>390</td><td>400</td><td>412</td>
</tr>
<tr>
<td class="sticky-col">L</td>
<td class="sticky-col">Front Center (mm)</td>
<td>574</td><td>577</td><td>581</td><td>593</td><td>606</td><td>616</td>
</tr>
<tr>
<td class="sticky-col">O</td>
<td class="sticky-col">Stand-over Height (mm)</td>
<td>737</td><td>752</td><td>772</td><td>789</td><td>807</td><td>830</td>
</tr>
<tr>
<td class="sticky-col"></td>
<td class="sticky-col">Trail (mm)</td>
<td>65</td><td>58</td><td>62</td><td>60</td><td>58</td><td>52</td>
</tr>


<tr class="section-row">
<td class="sticky-col">Components</td>
<td class="sticky-col"></td>
<td></td><td></td><td></td><td></td><td></td><td></td>
</tr>

<tr>
<td class="sticky-col"></td>
<td class="sticky-col">Stem (mm)</td>
<td>90</td><td>100</td><td>110</td><td>110</td><td>120</td><td>120</td>
</tr>
<tr>
<td class="sticky-col"></td>
<td class="sticky-col">Handlebar (mm)</td>
<td>360</td><td>360</td><td>380</td><td>380</td><td>400</td><td>400</td>
</tr>
<tr>
<td class="sticky-col"></td>
<td class="sticky-col">Crankset (mm)</td>
<td>165</td><td>165</td><td>170</td><td>170</td><td>172.5</td><td>172.5</td>
</tr>
<tr>
<td class="sticky-col"></td>
<td class="sticky-col">Seat Post (mm)</td>
<td>300</td><td>300</td><td>350</td><td>350</td><td>400</td><td>400</td>
</tr>

</tbody>
</table>
</div>
</div>
