Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0
Specialized Turbo Vado 3 X 4.0

Specialized Turbo Vado 3 X 4.0

SKU 91627-5002
$9,900.00 - $9,900.00
$9,900.00
$9,900.00 - $9,900.00
$9,900.00

Interested in this bike? Please email us or use the ENQUIRY FORM below to check your size and availability.

The bike may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY OF BIKES NATIONWIDE.

NOTE: Afterpay is unavailable on bike purchases.

Color: Gloss Agave Grey / Oak Green Metallic / Brushed Chrome Decal
Size: S
ENQUIRY

Turbo Vado 3 X 4.0

Take A Ride on The Wild Side

When the ride demands more, Vado 3 X answers. From urban adventures to off-road trekking, this is effortless power, elevated by full-suspension confidence. Born from Levo 4’s SuperNatural DNA with instinctive power, exceptional comfort, and incredible ride-anywhere range. With its class-leading features like our Turbo System Lock and built-in Apple Find My, Vado 3 X keeps every ride calm, composed, and in control wherever the journey leads. The art of arrival - perfected.

At a Glance

  • Use- Full-suspension all-terrain e-bike
  • E-Bike System- Specialized 3.1 motor w/ 810 W & 105 Nm, 840 Wh Battery with up to 150 km range
  • Tires- All-terrain tires: 2.6" Hemisphere
  • Display- Customizable color display
  • Anti-Theft- Battery and Turbo system lock, with built-in Apple Find My
  • Phone Charging- USB-C port on the side of the screen for easy phone charging

<div class="tech-specs">

<div class="spec-section">
<h4>E-bike</h4>

<div class="spec-item">
<p class="label">Battery</p>
<p class="value">Specialized Turbo 840Wh, with ABUS key lock</p>
</div>

<div class="spec-item">
<p class="label">Motor</p>
<p class="value">Specialized 3.1 Motor, 105Nm torque, 810W power</p>
</div>

<div class="spec-item">
<p class="label">Charger</p>
<p class="value">Specialized 4A Charger</p>
</div>

<div class="spec-item">
<p class="label">UI / Remote</p>
<p class="value">Turbo ergonomic remote</p>
</div>
</div>

<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">Vado X frame, premium comfort with 120mm rear travel, side-entry battery</p>
</div>

<div class="spec-item">
<p class="label">Seat Binder</p>
<p class="value">Alloy, 38.6mm</p>
</div>
</div>

<div class="spec-section">
<h4>Suspension</h4>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">SR Suntour suspension fork, 130mm travel, 34mm stanchions, 15mm thru-axle, 27.5" wheel</p>
</div>

<div class="spec-item">
<p class="label">Rear Shock</p>
<p class="value">RockShox Deluxe Select rear suspension, 120mm travel</p>
</div>
</div>

<div class="spec-section">
<h4>Brakes</h4>

<div class="spec-item">
<p class="label">Front Brake</p>
<p class="value">TEKTRO HD-T5040, 4-piston caliper, 2.3mm rotor, 5mm brake pads</p>
</div>

<div class="spec-item">
<p class="label">Rear Brake</p>
<p class="value">TEKTRO HD-T5040, 4-piston caliper, 2.3mm rotor, 5mm brake pads</p>
</div>
</div>

<div class="spec-section">
<h4>Drivetrain</h4>

<div class="spec-item">
<p class="label">Crankset</p>
<p class="value">170mm, CL 55mm, 110 BCD, 48T with chain guard</p>
</div>

<div class="spec-item">
<p class="label">Chainring</p>
<p class="value">48T with Chain Retention Technology</p>
</div>

<div class="spec-item">
<p class="label">Rear Derailleur</p>
<p class="value">Shimano CUES, 11-speed with Shadow Plus</p>
</div>

<div class="spec-item">
<p class="label">Shift Levers</p>
<p class="value">Shimano CUES RAPIDFIRE PLUS, right, 10-speed</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">Shimano CUES, 10-speed, 11-48T</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">Shimano LG</p>
</div>
</div>

<div class="spec-section">
<h4>Wheels &amp; Tyres</h4>

<div class="spec-item">
<p class="label">Rims</p>
<p class="value">27.5" front & rear, 30mm internal width, 32H</p>
</div>

<div class="spec-item">
<p class="label">Front Hub</p>
<p class="value">Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28H</p>
</div>

<div class="spec-item">
<p class="label">Rear Hub</p>
<p class="value">Specialized alloy rear disc hub, sealed cartridge bearings, 6-bolt, 12x148mm thru-axle, 32H, HG steel freehub</p>
</div>

<div class="spec-item">
<p class="label">Spokes</p>
<p class="value">DT Swiss Elemental</p>
</div>

<div class="spec-item">
<p class="label">Front Tyre</p>
<p class="value">Specialized Hemisphere Flat Resistant All-Terrain Reflect, 27.5x2.6</p>
</div>

<div class="spec-item">
<p class="label">Rear Tyre</p>
<p class="value">Specialized Hemisphere Flat Resistant All-Terrain Reflect, 27.5x2.6</p>
</div>

<div class="spec-item">
<p class="label">Inner Tubes</p>
<p class="value">Reinforced anti-flat 27.5x2.5/2.7, 60mm Schrader valve</p>
</div>
</div>

<div class="spec-section">
<h4>Cockpit</h4>

<div class="spec-item">
<p class="label">Handlebars</p>
<p class="value">Alloy, 34.4mm rise, 31.8mm clamp, 13° backsweep, 7.8° upsweep, 22.2mm bar end, 690–730mm width</p>
</div>

<div class="spec-item">
<p class="label">Stem</p>
<p class="value">Stem with integrated colour display and USB-C phone charger, 31.8mm</p>
</div>

<div class="spec-item">
<p class="label">Seatpost</p>
<p class="value">Dropper seatpost, 34.9mm, 0mm offset, 100/125/150mm travel</p>
</div>

<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">Body Geometry Rivo 2 Gel, 168mm</p>
</div>

<div class="spec-item">
<p class="label">Grips</p>
<p class="value">Specialized Body Geometry</p>
</div>
</div>

<div class="spec-section">
<h4>Accessories</h4>

<div class="spec-item">
<p class="label">Rear Rack</p>
<p class="value">25kg rear rack with integrated straps, QL3.1, MIK Stud, Arkel</p>
</div>

<div class="spec-item">
<p class="label">Kickstand</p>
<p class="value">Adjustable alloy kickstand</p>
</div>

<div class="spec-item">
<p class="label">Bell</p>
<p class="value">Bell included</p>
</div>

<div class="spec-item">
<p class="label">Fenders</p>
<p class="value">Extra-long fenders with water diffusion and durable metal construction</p>
</div>

<div class="spec-item">
<p class="label">Bike Lock</p>
<p class="value">ABUS key-secured battery lock</p>
</div>

<div class="spec-item">
<p class="label">Headlight</p>
<p class="value">Lezyne POWER StVZO E500+, 500 lumens with reflector</p>
</div>

<div class="spec-item">
<p class="label">SWAT</p>
<p class="value">MIK 25kg rear rack with integrated elastics, compatible with optional 10kg MIK front rack</p>
</div>

<div class="spec-item">
<p class="label">Taillight</p>
<p class="value">Rack-integrated taillight with automatic brake detection</p>
</div>

<div class="spec-item">
<p class="label">Pedals</p>
<p class="value">Turbo anti-slip pedals</p>
</div>
</div>

<div class="spec-section">
<h4>Product Details</h4>

<div class="spec-item">
<p class="label">Compliance Certification</p>
<p class="value">Certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS where applicable.</p>
</div>
</div>

<div class="spec-section">
<h4>Weight</h4>

<div class="spec-item">
<p class="label">Weight</p>
<p class="value">30.9 kg (68 lb, 2.0 oz)</p>
</div>

<div class="spec-item">
<p class="label">Weight Size</p>
<p class="value">MD</p>
</div>
</div>

</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col">Measurement</th>
<th>S</th>
<th>M</th>
<th>L</th>
<th>XL</th>
</tr>
</thead>
<tbody>

<tr>
<td class="sticky-col">Crank Length (mm)</td>
<td>170</td>
<td>170</td>
<td>170</td>
<td>170</td>
</tr>

<tr>
<td class="sticky-col">Handlebar Width (mm)</td>
<td>730</td>
<td>730</td>
<td>730</td>
<td>730</td>
</tr>

<tr>
<td class="sticky-col">Stem Length (mm)</td>
<td>60</td>
<td>60</td>
<td>60</td>
<td>60</td>
</tr>

<tr>
<td class="sticky-col">Saddle Width (mm)</td>
<td>168</td>
<td>168</td>
<td>168</td>
<td>168</td>
</tr>

<tr>
<td class="sticky-col">Seatpost Length (mm)</td>
<td>345</td>
<td>402</td>
<td>402</td>
<td>445</td>
</tr>

<tr>
<td class="sticky-col">Stack (mm)</td>
<td>618</td>
<td>625</td>
<td>640</td>
<td>667</td>
</tr>

<tr>
<td class="sticky-col">Reach (mm)</td>
<td>430</td>
<td>450</td>
<td>475</td>
<td>500</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Length (mm)</td>
<td>131</td>
<td>139</td>
<td>155</td>
<td>185</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Angle (°)</td>
<td>66</td>
<td>66</td>
<td>66</td>
<td>66</td>
</tr>

<tr>
<td class="sticky-col">BB Height (mm)</td>
<td>330</td>
<td>330</td>
<td>330</td>
<td>330</td>
</tr>

<tr>
<td class="sticky-col">BB Drop to Front (mm)</td>
<td>30</td>
<td>30</td>
<td>30</td>
<td>30</td>
</tr>

<tr>
<td class="sticky-col">Trail (mm)</td>
<td>112</td>
<td>112</td>
<td>112</td>
<td>112</td>
</tr>

<tr>
<td class="sticky-col">Fork Length, Full (mm)</td>
<td>531</td>
<td>531</td>
<td>531</td>
<td>531</td>
</tr>

<tr>
<td class="sticky-col">Fork Rake / Offset (mm)</td>
<td>44</td>
<td>44</td>
<td>44</td>
<td>44</td>
</tr>

<tr>
<td class="sticky-col">Front Center (mm)</td>
<td>740</td>
<td>764</td>
<td>795</td>
<td>832</td>
</tr>

<tr>
<td class="sticky-col">Chainstay Length (mm)</td>
<td>473</td>
<td>473</td>
<td>473</td>
<td>473</td>
</tr>

<tr>
<td class="sticky-col">Wheelbase (mm)</td>
<td>1212</td>
<td>1235</td>
<td>1267</td>
<td>1304</td>
</tr>

<tr>
<td class="sticky-col">Top Tube Length, Horizontal (mm)</td>
<td>665</td>
<td>700</td>
<td>607</td>
<td>632</td>
</tr>

<tr>
<td class="sticky-col">Bike Stand-Over Height (mm)</td>
<td>747</td>
<td>747</td>
<td>747</td>
<td>747</td>
</tr>

<tr>
<td class="sticky-col">Seat Tube Length (mm)</td>
<td>390</td>
<td>415</td>
<td>435</td>
<td>460</td>
</tr>

<tr>
<td class="sticky-col">Seat Tube Angle (°)</td>
<td>74</td>
<td>74</td>
<td>74</td>
<td>73</td>
</tr>

</tbody>
</table>
</div>
</div>
