Name: Specialized S-Works Tarmac SL9 Frameset
Brand: SPECIALIZED
SKU: 74927-0349
Price: 9500.0 NZD
Availability: InStock

Specialized S-Works Tarmac SL9 Frameset

SKU 74927-0349

$9,500.00 - $9,500.00

$9,500.00

$9,500.00 - $9,500.00

$9,500.00

Please email us or use the ENQUIRY FORM below to check your size and availability.

The frame may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY NATIONWIDE.

NOTE: Afterpay is unavailable on frame purchases.

S-Works Tarmac SL9 Frameset

One Bike To Rule Them All

The all-new S-Works Tarmac SL9 is the fastest road bike ever made. Not just because it’s the lightest. Not just because it’s our most aero. Not because it handles better than anything else on the road. But because it delivers the lowest real-world Time to Finish of any road bike ever made. Tarmac SL9 turns more of your effort into pure speed—validated for real race courses, real terrain, real riders. When the goal is to cross the line first, no road bike gets you there faster.

At a Glance

Use- Road Racing
Frame- FACT 12r Carbon - 687 grams
Fork- FACT 12r Carbon
Headset-Ceramic Speed SLT
Seatpost- S-Works Rapide Post
Weight- 1.39 kg

<div class="tech-specs">

<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">S-Works Tarmac SL9 FACT 12r Carbon, Rider First Engineered™, Win Tunnel Engineered™, CeramicSpeed SLT headset bearings, threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout</p>
</div>

</div>

<div class="spec-section">
<h4>Suspension</h4>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">S-Works FACT 12r Carbon, 12x100mm thru-axle, flat-mount disc</p>
</div>

</div>

<div class="spec-section">
<h4>Cockpit</h4>

<div class="spec-item">
<p class="label">Seatpost</p>
<p class="value">S-Works Rapide Post, FACT Carbon, 15mm offset</p>
</div>

<div class="spec-item">
<p class="label">Seat Binder</p>
<p class="value">Tarmac Integrated Wedge</p>
</div>

</div>

<div class="spec-section">
<h4>Weight</h4>

<div class="spec-item">
<p class="label">Weight</p>
<p class="value">1.39 kg (3 lb, 1.0 oz)</p>
</div>

<div class="spec-item">
<p class="label">Weight Size</p>
<p class="value">56</p>
</div>

</div>

</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col">Measurement</th>
<th>44</th>
<th>49</th>
<th>52</th>
<th>54</th>
<th>56</th>
<th>58</th>
<th>61</th>
</tr>
</thead>
<tbody>

<tr>
<td class="sticky-col">Seatpost Length (mm)</td>
<td>300</td>
<td>300</td>
<td>300</td>
<td>380</td>
<td>380</td>
<td>380</td>
<td>380</td>
</tr>

<tr>
<td class="sticky-col">Frame Stack (mm)</td>
<td>501</td>
<td>514</td>
<td>527</td>
<td>544</td>
<td>565</td>
<td>591</td>
<td>612</td>
</tr>

<tr>
<td class="sticky-col">Frame Reach (mm)</td>
<td>366</td>
<td>375</td>
<td>380</td>
<td>384</td>
<td>395</td>
<td>402</td>
<td>408</td>
</tr>

<tr>
<td class="sticky-col">Stack to Stem (mm)</td>
<td>509</td>
<td>522</td>
<td>535</td>
<td>552</td>
<td>573</td>
<td>599</td>
<td>620</td>
</tr>

<tr>
<td class="sticky-col">Reach to Stem (mm)</td>
<td>363</td>
<td>372</td>
<td>377</td>
<td>381</td>
<td>393</td>
<td>400</td>
<td>406</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Length (mm)</td>
<td>99</td>
<td>109</td>
<td>120</td>
<td>140</td>
<td>157</td>
<td>184</td>
<td>204</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Angle (°)</td>
<td>70.5</td>
<td>71.75</td>
<td>72.5</td>
<td>72.5</td>
<td>73.5</td>
<td>73.5</td>
<td>74</td>
</tr>

<tr>
<td class="sticky-col">BB Height (mm)</td>
<td>266</td>
<td>266</td>
<td>266</td>
<td>268</td>
<td>268</td>
<td>268</td>
<td>268</td>
</tr>

<tr>
<td class="sticky-col">BB Drop (mm)</td>
<td>74</td>
<td>74</td>
<td>74</td>
<td>72</td>
<td>72</td>
<td>72</td>
<td>72</td>
</tr>

<tr>
<td class="sticky-col">Trail (mm)</td>
<td>71</td>
<td>63</td>
<td>58</td>
<td>58</td>
<td>55</td>
<td>55</td>
<td>52</td>
</tr>

<tr>
<td class="sticky-col">Fork Length, Full (mm)</td>
<td>370</td>
<td>370</td>
<td>370</td>
<td>370</td>
<td>370</td>
<td>370</td>
<td>370</td>
</tr>

<tr>
<td class="sticky-col">Fork Rake / Offset (mm)</td>
<td>47</td>
<td>47</td>
<td>47</td>
<td>47</td>
<td>44</td>
<td>44</td>
<td>44</td>
</tr>

<tr>
<td class="sticky-col">Front Center (mm)</td>
<td>567</td>
<td>570</td>
<td>572</td>
<td>582</td>
<td>587</td>
<td>602</td>
<td>609</td>
</tr>

<tr>
<td class="sticky-col">Chainstay Length (mm)</td>
<td>410</td>
<td>410</td>
<td>410</td>
<td>410</td>
<td>410</td>
<td>410</td>
<td>410</td>
</tr>

<tr>
<td class="sticky-col">Wheelbase (mm)</td>
<td>970</td>
<td>973</td>
<td>975</td>
<td>986</td>
<td>991</td>
<td>1006</td>
<td>1013</td>
</tr>

<tr>
<td class="sticky-col">Top Tube Length, Horizontal (mm)</td>
<td>496</td>
<td>509</td>
<td>531</td>
<td>540</td>
<td>563</td>
<td>577</td>
<td>595</td>
</tr>

<tr>
<td class="sticky-col">Bike Standover Height (mm)</td>
<td>722</td>
<td>734</td>
<td>745</td>
<td>767</td>
<td>785</td>
<td>807</td>
<td>833</td>
</tr>

<tr>
<td class="sticky-col">Seat Tube Length (mm)</td>
<td>433</td>
<td>445</td>
<td>456</td>
<td>473</td>
<td>494</td>
<td>515</td>
<td>545</td>
</tr>

<tr>
<td class="sticky-col">Seat Tube Angle (°)</td>
<td>75.5</td>
<td>75.5</td>
<td>74</td>
<td>74</td>
<td>73.5</td>
<td>73.5</td>
<td>73</td>
</tr>

</tbody>
</table>
</div>
</div>

Specialized S-Works Tarmac SL9 Frameset

Product Details

S-Works Tarmac SL9 Frameset

Technical Specifications

Geometry
