Name: Specialized S-Works Crux 5
Brand: iRIDE Store
SKU: 91427-0052
Price: 21900.0 NZD
Availability: InStock

Specialized S-Works Crux 5

SKU 91427-0052

$21,900.00 - $21,900.00

$21,900.00

$21,900.00 - $21,900.00

$21,900.00

Interested in this bike? Please email us or use the ENQUIRY FORM below to check your size and availability.

The bike may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY OF BIKES NATIONWIDE.

NOTE: Afterpay is unavailable on bike purchases.

S-Works Crux 5

Eat My Dust

The S-Works Crux 5 is the fastest gravel race bike ever made. Not just because it’s the lightest. Not just because it’s our most aero. Not just because it handles dirt like a Tarmac handles pavement. But because it delivers the lowest real-world Time to Finish of any gravel bike ever made. Crux 5 turns more of your effort into pure speed—validated across real race courses, real terrain, and real riders. When the goal is the top step, nothing in gravel gets you there faster.

<div class="tech-specs">


<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">S-Works Crux 5 FACT 12r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout</p>
</div>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc</p>
</div>

</div>


<div class="spec-section">
<h4>Brakes</h4>

<div class="spec-item">
<p class="label">Front Brake</p>
<p class="value">SRAM RED E1, hydraulic disc</p>
</div>

<div class="spec-item">
<p class="label">Rear Brake</p>
<p class="value">SRAM RED E1, hydraulic disc</p>
</div>

</div>


<div class="spec-section">
<h4>Drivetrain</h4>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">Ceramic Speed BB Alpha, BSA DUB</p>
</div>

<div class="spec-item">
<p class="label">Shift Levers</p>
<p class="value">SRAM RED AXS E1, hydraulic disc</p>
</div>

<div class="spec-item">
<p class="label">Rear Derailleur</p>
<p class="value">SRAM RED AXS XPLR E1, 13-speed</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">SRAM RED E1</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">SRAM RED XPLR E1, 13-speed, 10-46t</p>
</div>

<div class="spec-item">
<p class="label">Crankset</p>
<p class="value">SRAM RED XPLR E1, Quarq power meter, 40t</p>
</div>

</div>


<div class="spec-section">
<h4>Wheels & Tires</h4>

<div class="spec-item">
<p class="label">Front Wheel</p>
<p class="value">Roval Terra Aero CLX, 27mm internal width, tubeless ready, 50mm depth, 18h, Roval LF18-F hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS Composite Aero Spokes with Ti End Pieces</p>
</div>

<div class="spec-item">
<p class="label">Rear Wheel</p>
<p class="value">Roval Terra Aero CLX, 27mm internal width, tubeless ready, 45mm depth, 24h, Roval LF19-R hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS Composite Aero Spokes with Ti End Pieces</p>
</div>

<div class="spec-item">
<p class="label">Front Tire</p>
<p class="value">Pathfinder 700x45, Tubeless Ready</p>
</div>

<div class="spec-item">
<p class="label">Rear Tire</p>
<p class="value">Pathfinder 700x45, Tubeless Ready</p>
</div>

<div class="spec-item">
<p class="label">Inner Tubes</p>
<p class="value">700x32-50mm, 60mm Presta valve</p>
</div>

</div>


<div class="spec-section">
<h4>Cockpit</h4>

<div class="spec-item">
<p class="label">Handlebars</p>
<p class="value">Roval Terra Cockpit, Integrated Bar/Stem</p>
</div>

<div class="spec-item">
<p class="label">SeatPost</p>
<p class="value">S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset, Lightweight Saddle Clamp</p>
</div>

<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">S-Works Power with Mirror</p>
</div>

<div class="spec-item">
<p class="label">Tape</p>
<p class="value">Supacaz Super Sticky Kush</p>
</div>

<div class="spec-item">
<p class="label">Seat Binder</p>
<p class="value">Integrated Wedge</p>
</div>

</div>


<div class="spec-section">
<h4>Weight</h4>

<div class="spec-item">
<p class="label">Weight</p>
<p class="value">7.1 kg (15 lb, 10.4 oz)</p>
</div>

<div class="spec-item">
<p class="label">Weight Size</p>
<p class="value">56</p>
</div>

</div>

</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col label-col"></th>
<th>49</th>
<th>52</th>
<th>54</th>
<th>56</th>
<th>58</th>
<th>61</th>
</tr>
</thead>

<tbody>
<tr>
<td class="sticky-col label-col">Crank Length</td>
<td>165</td>
<td>165</td>
<td>170</td>
<td>170</td>
<td>172.5</td>
<td>172.5</td>
</tr>

<tr>
<td class="sticky-col label-col">Handlebar Width</td>
<td>380</td>
<td>380</td>
<td>400</td>
<td>400</td>
<td>420</td>
<td>420</td>
</tr>

<tr>
<td class="sticky-col label-col">Stem Length</td>
<td>75</td>
<td>90</td>
<td>90</td>
<td>100</td>
<td>100</td>
<td>100</td>
</tr>

<tr>
<td class="sticky-col label-col">Saddle Width</td>
<td>155</td>
<td>155</td>
<td>143</td>
<td>143</td>
<td>143</td>
<td>143</td>
</tr>

<tr>
<td class="sticky-col label-col">Seatpost Length</td>
<td>300</td>
<td>300</td>
<td>380</td>
<td>380</td>
<td>380</td>
<td>380</td>
</tr>

<tr>
<td class="sticky-col label-col">Stack</td>
<td>530</td>
<td>547</td>
<td>560</td>
<td>578</td>
<td>598</td>
<td>621</td>
</tr>

<tr>
<td class="sticky-col label-col">Reach</td>
<td>375</td>
<td>382</td>
<td>388</td>
<td>400</td>
<td>412</td>
<td>425</td>
</tr>

<tr>
<td class="sticky-col label-col">Head Tube Length</td>
<td>95</td>
<td>110</td>
<td>125</td>
<td>142</td>
<td>163</td>
<td>188</td>
</tr>

<tr>
<td class="sticky-col label-col">Head Tube Angle</td>
<td>70.5</td>
<td>70.75</td>
<td>71</td>
<td>71.5</td>
<td>71.5</td>
<td>71.5</td>
</tr>

<tr>
<td class="sticky-col label-col">BB Height</td>
<td>278</td>
<td>278</td>
<td>280</td>
<td>280</td>
<td>280</td>
<td>280</td>
</tr>

<tr>
<td class="sticky-col label-col">BB Drop</td>
<td>80</td>
<td>80</td>
<td>78</td>
<td>78</td>
<td>78</td>
<td>78</td>
</tr>

<tr>
<td class="sticky-col label-col">Trail</td>
<td>72</td>
<td>71</td>
<td>69</td>
<td>66</td>
<td>66</td>
<td>66</td>
</tr>

<tr>
<td class="sticky-col label-col">Fork Length, Full</td>
<td>401</td>
<td>401</td>
<td>401</td>
<td>401</td>
<td>401</td>
<td>401</td>
</tr>

<tr>
<td class="sticky-col label-col">Fork Rake/Offset</td>
<td>51</td>
<td>51</td>
<td>51</td>
<td>51</td>
<td>51</td>
<td>51</td>
</tr>

<tr>
<td class="sticky-col label-col">Front Center</td>
<td>594</td>
<td>604</td>
<td>613</td>
<td>626</td>
<td>644</td>
<td>665</td>
</tr>

<tr>
<td class="sticky-col label-col">Chainstay Length</td>
<td>425</td>
<td>425</td>
<td>425</td>
<td>425</td>
<td>425</td>
<td>425</td>
</tr>

<tr>
<td class="sticky-col label-col">Wheelbase</td>
<td>1008</td>
<td>1016</td>
<td>1026</td>
<td>1039</td>
<td>1057</td>
<td>1078</td>
</tr>

<tr>
<td class="sticky-col label-col">Top Tube Length, Horizontal</td>
<td>512</td>
<td>534</td>
<td>543</td>
<td>566</td>
<td>583</td>
<td>603</td>
</tr>

<tr>
<td class="sticky-col label-col">Bike Standover Height</td>
<td>753</td>
<td>766</td>
<td>781</td>
<td>803</td>
<td>823</td>
<td>849</td>
</tr>

<tr>
<td class="sticky-col label-col">Seat Tube Length</td>
<td>445</td>
<td>456</td>
<td>473</td>
<td>497</td>
<td>515</td>
<td>545</td>
</tr>

<tr>
<td class="sticky-col label-col">Seat Tube Angle</td>
<td>75.5</td>
<td>74.5</td>
<td>74.5</td>
<td>74</td>
<td>74</td>
<td>74</td>
</tr>

</tbody>
</table>
</div>
</div>
