Name: Specialized - Crux Comp
Brand: SPECIALIZED
SKU: 91426-5049
Price: 6500.0 NZD
Availability: InStock

Specialized - Crux Comp

SKU 91426-5049

$6,500.00 - $6,500.00

$6,500.00

$6,500.00 - $6,500.00

$6,500.00

Interested in this bike? Please email us or use the ENQUIRY FORM below to check your size and availability.

The bike may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY OF BIKES NATIONWIDE.

NOTE: Afterpay is unavailable on bike purchases.

The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tire clearance and performance gravel geometry. It’s not just the ultimate expression of gravel performance, it’s your one-way ticket to gravel enlightenment.

This Crux Comp comes spec'd with a reliable and smooth-shifting Shimano GRX 12-speed groupset, tough DT G540 Disc wheels, and 2Bliss Ready, 700x40mm Pathfinder tires that hookup over nasty terrain.

Lightest: 725g S-Works 12r and 825g 10r frames. We took the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over nightmarish terrain, and weighs less than a full bottle in your cage.
Capable: 47c/650b x 2.1” tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine, at full gas.
Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux’s iconic history in ‘cross.

<div class="tech-specs">

<div class="spec-section">
<h4>Frameset</h4>
<div class="spec-item">
<p class="label">Frame</p>
<p class="value">
Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB,
12x142mm thru-axle, flat-mount disc, UDH dropout
</p>
</div>
</div>

<div class="spec-section">
<h4>Suspension</h4>
<div class="spec-item">
<p class="label">Fork</p>
<p class="value">
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
</p>
</div>
</div>

<div class="spec-section">
<h4>Brakes</h4>
<div class="spec-item">
<p class="label">Front Brake</p>
<p class="value">Shimano GRX RX820</p>
</div>
<div class="spec-item">
<p class="label">Rear Brake</p>
<p class="value">Shimano GRX RX820</p>
</div>
</div>

<div class="spec-section">
<h4>Drivetrain</h4>
<div class="spec-item">
<p class="label">Shift Levers</p>
<p class="value">Shimano GRX ST-RX820</p>
</div>
<div class="spec-item">
<p class="label">Rear Derailleur</p>
<p class="value">Shimano GRX RX822-GS, 12-speed</p>
</div>
<div class="spec-item">
<p class="label">Crankset</p>
<p class="value">Shimano GRX RX820, 40t</p>
</div>
<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">Shimano Threaded BSA BB</p>
</div>
<div class="spec-item">
<p class="label">Chain</p>
<p class="value">Shimano XT CN-M8100, 12-speed</p>
</div>
<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">Shimano XT, 12-speed, 10–45t</p>
</div>
</div>

<div class="spec-section">
<h4>Wheels & Tires</h4>
<div class="spec-item">
<p class="label">Front Wheel</p>
<p class="value">
DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h,
Specialized sealed bearing hub, Centerlock disc,
DT Swiss Champion 14G stainless spokes, DT Swiss brass nipples
</p>
</div>
<div class="spec-item">
<p class="label">Rear Wheel</p>
<p class="value">
DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h,
Specialized sealed bearing hub, Centerlock disc,
DT Swiss Champion 14G stainless spokes, DT Swiss brass nipples
</p>
</div>
<div class="spec-item">
<p class="label">Front Tire</p>
<p class="value">Pathfinder 700x40, Tubeless Ready</p>
</div>
<div class="spec-item">
<p class="label">Rear Tire</p>
<p class="value">Pathfinder 700x40, Tubeless Ready</p>
</div>
<div class="spec-item">
<p class="label">Inner Tubes</p>
<p class="value">700x32–50mm, 40mm Presta valve</p>
</div>
</div>

<div class="spec-section">
<h4>Cockpit</h4>
<div class="spec-item">
<p class="label">Handlebars</p>
<p class="value">Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare</p>
</div>
<div class="spec-item">
<p class="label">Stem</p>
<p class="value">3D-forged alloy, 31.8mm, 7-degree rise</p>
</div>
<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">Body Geometry Power Sport, steel rails</p>
</div>
<div class="spec-item">
<p class="label">SeatPost</p>
<p class="value">Roval Terra Carbon Seat Post, 20mm Offset</p>
</div>
<div class="spec-item">
<p class="label">Seat Binder</p>
<p class="value">Specialized Alloy, 30mm</p>
</div>
<div class="spec-item">
<p class="label">Tape</p>
<p class="value">Supacaz Super Sticky Kush</p>
</div>
</div>

<div class="spec-section">
<h4>Weight</h4>
<div class="spec-item">
<p class="label">Weight</p>
<p class="value">8.66 kg (19 lb, 1.5 oz)</p>
</div>
<div class="spec-item">
<p class="label">Weight Size</p>
<p class="value">56</p>
</div>
</div>

</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col"></th>
<th>49</th><th>52</th><th>54</th><th>56</th><th>58</th><th>61</th>
</tr>
</thead>
<tbody>

<tr><th class="sticky-col">Crank Length (mm)</th>
<td>170</td><td>170</td><td>172.5</td><td>172.5</td><td>175</td><td>175</td></tr>

<tr><th class="sticky-col">Handlebar Width (mm)</th>
<td>380</td><td>400</td><td>420</td><td>420</td><td>440</td><td>440</td></tr>

<tr><th class="sticky-col">Stem Length (mm)</th>
<td>70</td><td>80</td><td>90</td><td>100</td><td>110</td><td>110</td></tr>

<tr><th class="sticky-col">Saddle Width (mm)</th>
<td>155</td><td>155</td><td>143</td><td>143</td><td>143</td><td>143</td></tr>

<tr><th class="sticky-col">Seatpost Length (mm)</th>
<td>330</td><td>330</td><td>330</td><td>380</td><td>380</td><td>380</td></tr>

<tr class="section-row"><th class="sticky-col">Frame Geometry</th><td colspan="6"></td></tr>

<tr><th class="sticky-col">Stack (mm)</th>
<td>530</td><td>547</td><td>560</td><td>578</td><td>598</td><td>621</td></tr>

<tr><th class="sticky-col">Reach (mm)</th>
<td>375</td><td>382</td><td>388</td><td>397</td><td>405</td><td>415</td></tr>

<tr><th class="sticky-col">Head Tube Length (mm)</th>
<td>100</td><td>115</td><td>130</td><td>147</td><td>167</td><td>190</td></tr>

<tr><th class="sticky-col">Head Tube Angle (°)</th>
<td>70.5</td><td>71.25</td><td>71.5</td><td>72</td><td>72.25</td><td>72.5</td></tr>

<tr><th class="sticky-col">BB Height (mm)</th>
<td>284</td><td>284</td><td>286</td><td>286</td><td>286</td><td>286</td></tr>

<tr><th class="sticky-col">BB Drop (mm)</th>
<td>74</td><td>74</td><td>72</td><td>72</td><td>72</td><td>72</td></tr>

<tr><th class="sticky-col">Trail (mm)</th>
<td>74</td><td>69</td><td>67</td><td>64</td><td>62</td><td>60</td></tr>

<tr><th class="sticky-col">Fork Length, Full (mm)</th>
<td>401</td><td>401</td><td>401</td><td>401</td><td>401</td><td>401</td></tr>

<tr><th class="sticky-col">Fork Rake / Offset (mm)</th>
<td>50</td><td>50</td><td>50</td><td>50</td><td>50</td><td>50</td></tr>

<tr><th class="sticky-col">Front Center (mm)</th>
<td>594</td><td>600</td><td>608</td><td>618</td><td>630</td><td>644</td></tr>

<tr><th class="sticky-col">Chainstay Length (mm)</th>
<td>425</td><td>425</td><td>425</td><td>425</td><td>425</td><td>425</td></tr>

<tr><th class="sticky-col">Wheelbase (mm)</th>
<td>1008</td><td>1014</td><td>1023</td><td>1033</td><td>1045</td><td>1059</td></tr>

<tr><th class="sticky-col">Top Tube Length, Horizontal (mm)</th>
<td>512</td><td>539</td><td>549</td><td>568</td><td>582</td><td>599</td></tr>

<tr><th class="sticky-col">Bike Standover Height (mm)</th>
<td>749</td><td>772</td><td>794</td><td>816</td><td>841</td><td>866</td></tr>

<tr><th class="sticky-col">Seat Tube Length (mm)</th>
<td>466</td><td>496</td><td>521</td><td>546</td><td>576</td><td>606</td></tr>

<tr><th class="sticky-col">Seat Tube Angle (°)</th>
<td>75.5</td><td>74</td><td>74</td><td>73.5</td><td>73.5</td><td>73.5</td></tr>

</tbody>
</table>
</div>
</div>
