For years, time trial bikes have had very similar attributes—skinny, deep airfoils, sketchy handling, subpar braking, and heavy frames. For the 'flat and fast' courses of yesteryear, these qualities may have been acceptable, but with today's technically demanding courses, TT bikes needed a change. And with this in mind, we've pushed UCI regulations to their limits adding disc brakes, dropping weight, and dialing in the fit for the new Shiv TT. Is it the most adjustable TT bike out there? Yeah, but don't think it gave anything up to aerodynamics. Here's to another decade of gold medals.
The S-Works Shiv TT Disc Module is the perfect canvas to start constructing your TT dream rig.As time-trial courses have become more technical and demanding, it's important to capitalize on years of R&D and pro rider feedback to create the fastest time trial bike—for all courses. From technical inner-city prologues, to rolling courses with steep grades, it's not just about making the fastest bike for a straight line. With this in mind, we've cut the weight and greatly increased the handling characteristics of the Shiv TT with an all-new silhouette
Fit was also one of the biggest design pillars of the new Shiv TT. With years of Retül data, and professional rider data, we've completely re-done the geometry and front-end of the bike. The updated spacers, bridge, and armrests lock in fit, improving stability and confidence, while the one-piece bar and stem simplifies and lightens the weight of the front-end, balancing the overall feel.
Disc brakes are now a necessity in TTs with variable weather, tight corners, and rough surfaces. Not only do they let you late-brake into corners and shift on the bars, but they also create a more stable chassis in corners and when accelerating. And don't worry, they don't lend themselves to any additional drag.
Frameset FRAME S-Works FACT 11r carbon, Win Tunnel Engineered, UCI Legal, internal electric only cable routing, BSA Threaded, 12x142mm thru-axle, flat-mount disc Suspension FORK S-Works FACT carbon, UCI Legal, 100x12mm thru-axle, flat-mount disc Cockpit SEATPOST 2019 S-Works Venge aero seatpost, FACT carbon, Di2-compatible STEM Shiv TT Basebar with integrated stem cover SEAT BINDER Shiv TT integrated wedge HANDLEBARS Specialized Shiv TT Integrated bar/stem aerobar Product Details PRODUCT ID 221549 Weight WEIGHT 2.69 kg (5 lb, 14.9 oz) WEIGHT SIZE MD * Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
XS S M L Handlebar Width 400 400 400 400 Stem Length 75 75 75 75 Seatpost Length 390 390 390 390 Effective Reach to Center of Pad, REARWARD Position 436 448 463 478 Effective Stack to Pad Holder, HIGHEST Position 680 690 690 690 Trail 70 63 63 63 Stack 485 495 495 495 Fork Length (full) 363 363 363 363 Top-Tube Length (horizontal) 512 527 538 546 Seat-Tube Length 504 564 563 562 Reach 378 390 405 420 Head-Tube Angle 71 72 72 72 B-B Drop 70 72 72 72 Front-Center 573 579 594 609 Head-Tube Length 90 95 95 95 Chain-Stay Length 410 410 410 410 Effective Stack to Pad Holder, LOWEST Position 535 545 545 545 Bike Stand-Over Height 769 802 802 802 Effective Reach to Center of Pad, FORWARD Position 464 476 491 506 B-B Height 269 270 270 270 Wheelbase 972 978 993 1008 Fork Rake/Offset 45 45 45 45 Seat-Tube Angle 74.5 74.5 75 75.75
