Name: Specialized - S-Works Epic 9 LTD
Brand: SPECIALIZED
SKU: 90327-0304
Price: 26900.0 NZD
Availability: InStock

Specialized - S-Works Epic 9 LTD

SKU 90327-0304

$26,900.00 - $26,900.00

$26,900.00

$26,900.00 - $26,900.00

$26,900.00

Interested in this bike? Please email us or use the ENQUIRY FORM below to check your size and availability.

The bike may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY OF BIKES NATIONWIDE.

NOTE: Afterpay is unavailable on bike purchases.

Quantity

S-Works Epic 9 LTD Built for Legends

Evolution of the Fastest

Epic 9 represents 24 years of winning XC innovation, distilled into the fastest race bike in the world. The Built for Legends LTD celebrates the Epic bike's unrivaled racing heritage with an exclusive colorway, exclusive red brake claipers, and unique details inspired by two decades of World Cup domination. Limited to just 119 individually numbered bikes worldwide, it is as rare as it is fast. Once they’re gone, they’re gone forever.

We started with Epic 8, the benchmark in XC racing, and pushed it even further. At 206 grams lighter, Epic 9 is the lightest full-suspension XC frameset on the planet. We reduced suspension friction by 11% and refined the kinematics. The result: unmatched efficiency, capability, and speed per watt.<br>When the only goal is the top step, nothing in XC gets you there faster than the S-Works Epic 9 Built for Legends LTD.

At a Glance

Use- XC Racing
Exclusive LTD Edition- Only 119 Individually Numbered Bikes
Frame- S-Works FACT 12m Carbon, Progressive XC Race Geometry, 120mm of travel
Suspension- Front: RockShox SID Ultimate Flight Attendant<br>Rear: RockShox SIDLuxe Ultimate Flight Attendant
Drivetrain- SRAM XX SL Eagle Transmission
Weight- 21 lbs. 4.7 oz. (9.66 kg)

<div class="tech-specs">

<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">S-Works FACT 12m Carbon, Progressive XC Race Geometry, Rider-First Engineered™, threaded BB, 12x148mm UDH compatible rear dropout, internal cable routing, 120mm of travel, Optimized for wireless drivetrain</p>
</div>

<div class="spec-item">
<p class="label">SWAT</p>
<p class="value">SWAT BOX 2.0 ASSY</p>
</div>

<div class="spec-item">
<p class="label">Seat Binder</p>
<p class="value">Specialized Alloy 34.9, Ti Bolt</p>
</div>
</div>

<div class="spec-section">
<h4>Suspension</h4>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">RockShox SID ULTIMATE Flight Attendant, Ride Dynamics developed 3 position, Debon Air, 15x110mm, 44mm offset, 120mm Travel</p>
</div>

<div class="spec-item">
<p class="label">Rear Shock</p>
<p class="value">RockShox SIDLuxe ULTIMATE Flight Attendant, Ride Dynamics developed 3 position, Solo Air, 190x45mm</p>
</div>
</div>

<div class="spec-section">
<h4>Brakes</h4>

<div class="spec-item">
<p class="label">Front Brake</p>
<p class="value">SRAM Motive Ultimate, 4-piston caliper, hydraulic disc, 180mm rotor</p>
</div>

<div class="spec-item">
<p class="label">Rear Brake</p>
<p class="value">SRAM Motive Ultimate, 4-piston caliper, hydraulic disc, 160mm rotor</p>
</div>
</div>

<div class="spec-section">
<h4>Drivetrain</h4>

<div class="spec-item">
<p class="label">Chainrings</p>
<p class="value">32T</p>
</div>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">Ceramicspeed Alpha, DUB</p>
</div>

<div class="spec-item">
<p class="label">Crankset</p>
<p class="value">SRAM / Quarq XX SL Eagle Power Meter Crankset, DUB SM:165mm, M-XL:170mm, 34T</p>
</div>

<div class="spec-item">
<p class="label">Shift Levers</p>
<p class="value">SRAM AXS POD Ultimate Controller</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">SRAM CS-1299, 12 speed, 10-52t</p>
</div>

<div class="spec-item">
<p class="label">Rear Derailleur</p>
<p class="value">SRAM XX SL Eagle AXS</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">SRAM XX SL Eagle Transmission 12-Speed Flattop Chain</p>
</div>
</div>

<div class="spec-section">
<h4>Wheels & Tires</h4>

<div class="spec-item">
<p class="label">Front Wheel</p>
<p class="value">Roval Control World Cup, Mini hooked carbon, 28.5mm inner width, tubeless ready, Roval Control World Cup hub, DT Swiss ceramic bearings, Roval Carbon spokes w/ Ti end pieces</p>
</div>

<div class="spec-item">
<p class="label">Rear Wheel</p>
<p class="value">Roval Control World Cup, Mini hooked carbon, 28.5mm inner width, tubeless ready, Roval Control World Cup hub, DT Swiss 180 internals, Roval Carbon spokes w/ Ti end pieces</p>
</div>

<div class="spec-item">
<p class="label">Front Tire</p>
<p class="value">Specialized Fast Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35</p>
</div>

<div class="spec-item">
<p class="label">Rear Tire</p>
<p class="value">Specialized Air Trak, Flex Lite Casing, T5/T7 Compound, 29x2.35</p>
</div>

<div class="spec-item">
<p class="label">Inner Tubes</p>
<p class="value">Specialized TPU inner tube</p>
</div>
</div>

<div class="spec-section">
<h4>Cockpit</h4>

<div class="spec-item">
<p class="label">Seatpost</p>
<p class="value">RockShox Reverb AXS, 30.9mm, S: 125, M/L: 150, XL: 175mm</p>
</div>

<div class="spec-item">
<p class="label">Handlebars</p>
<p class="value">Roval Control SL Integrated cockpit, 60mm/70mm X- 6 degree integrated stem, 8-degree backsweep, 2 degree upsweep, 760mm wide</p>
</div>

<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">Specialized S-Works Power EVO Mirror, Carbon Rails, SM: 155mm, M-XL: 143mm</p>
</div>

<div class="spec-item">
<p class="label">Grips</p>
<p class="value">Specialized Trail Grips</p>
</div>
</div>

<div class="spec-section">
<h4>Weight</h4>

<div class="spec-item">
<p class="label">Weight</p>
<p class="value">9.69 kg (21 lb, 5.8 oz)</p>
</div>

<div class="spec-item">
<p class="label">Weight Size</p>
<p class="value">MD</p>
</div>
</div>

</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col">Measurement</th>
<th>S</th>
<th>M</th>
<th>L</th>
<th>XL</th>
</tr>
</thead>
<tbody>

<tr>
<td class="sticky-col">Crank Length (mm)</td>
<td>165</td><td>170</td><td>170</td><td>170</td>
</tr>

<tr>
<td class="sticky-col">Handlebar Width (mm)</td>
<td>760</td><td>760</td><td>760</td><td>760</td>
</tr>

<tr>
<td class="sticky-col">Stem Length (mm)</td>
<td>60</td><td>70</td><td>70</td><td>70</td>
</tr>

<tr>
<td class="sticky-col">Saddle Width (mm)</td>
<td>155</td><td>143</td><td>143</td><td>143</td>
</tr>

<tr>
<td class="sticky-col">Seatpost Length (mm)</td>
<td>125</td><td>150</td><td>150</td><td>175</td>
</tr>

<tr>
<td class="sticky-col">Stack (mm)</td>
<td>594</td><td>604</td><td>618</td><td>645</td>
</tr>

<tr>
<td class="sticky-col">Reach (Low) (mm)</td>
<td>420</td><td>450</td><td>480</td><td>505</td>
</tr>

<tr>
<td class="sticky-col">Reach (High) (mm)</td>
<td>425</td><td>455</td><td>485</td><td>510</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Length (mm)</td>
<td>92</td><td>105</td><td>120</td><td>150</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Angle (Low) (°)</td>
<td>65.9</td><td>65.9</td><td>65.9</td><td>65.9</td>
</tr>

<tr>
<td class="sticky-col">Head Tube Angle (High) (°)</td>
<td>66.3</td><td>66.3</td><td>66.3</td><td>66.3</td>
</tr>

<tr>
<td class="sticky-col">BB Height (mm)</td>
<td>333</td><td>335</td><td>335</td><td>335</td>
</tr>

<tr>
<td class="sticky-col">BB Drop (Low) (mm)</td>
<td>42</td><td>40</td><td>40</td><td>40</td>
</tr>

<tr>
<td class="sticky-col">BB Drop (High) (mm)</td>
<td>37</td><td>35</td><td>35</td><td>35</td>
</tr>

<tr>
<td class="sticky-col">Trail (mm)</td>
<td>120</td><td>120</td><td>120</td><td>120</td>
</tr>

<tr>
<td class="sticky-col">Fork Length, Full (mm)</td>
<td>531</td><td>531</td><td>531</td><td>531</td>
</tr>

<tr>
<td class="sticky-col">Fork Rake / Offset (mm)</td>
<td>44</td><td>44</td><td>44</td><td>44</td>
</tr>

<tr>
<td class="sticky-col">Front Center (mm)</td>
<td>716</td><td>752</td><td>788</td><td>823</td>
</tr>

<tr>
<td class="sticky-col">Chainstay Length (mm)</td>
<td>435</td><td>435</td><td>438</td><td>442</td>
</tr>

<tr>
<td class="sticky-col">Wheelbase (mm)</td>
<td>1148</td><td>1184</td><td>1223</td><td>1264</td>
</tr>

<tr>
<td class="sticky-col">Top Tube Length, Horizontal (mm)</td>
<td>568</td><td>601</td><td>634</td><td>666</td>
</tr>

<tr>
<td class="sticky-col">Frame Standover Height (mm)</td>
<td>749</td><td>755</td><td>757</td><td>764</td>
</tr>

<tr>
<td class="sticky-col">Seat Tube Length (mm)</td>
<td>390</td><td>410</td><td>455</td><td>505</td>
</tr>

<tr>
<td class="sticky-col">Seat Tube Angle (°)</td>
<td>76</td><td>76</td><td>76</td><td>76</td>
</tr>

<tr>
<td class="sticky-col">Seat Post Max Insertion (mm)</td>
<td>190</td><td>220</td><td>260</td><td>315</td>
</tr>

<tr>
<td class="sticky-col">Seat Post Min Insertion (mm)</td>
<td>80</td><td>80</td><td>80</td><td>80</td>
</tr>

<tr>
<td class="sticky-col">Saddle Height for Effective STA (mm)</td>
<td>690</td><td>735</td><td>780</td><td>825</td>
</tr>

</tbody>
</table>
</div>
</div>

Specialized - S-Works Epic 9 LTD

Product Details

S-Works Epic 9 LTD Built for Legends

Technical Specifications

Geometry
