Specialized - Crux Expert SRAM Rival XPLR AXS

Name: Specialized - Crux Expert SRAM Rival XPLR AXS
Brand: SPECIALIZED
SKU: 91426-3149
Price: 9500.0 NZD
Availability: InStock

SKU 91426-3149

$0.00 - $0.00

$9,500.00

$9,500.00 - $9,500.00

$9,500.00

Colour: Satin Carbon/nebula Metallic

Satin Carbon/nebula Metallic

Size: 49

49

52

54

56

58

61

❯ ❯ ❯ DESCRIPTION

ETA - From late August

The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tire clearance and performance gravel geometry. It’s not just the ultimate expression of gravel performance, it’s your one-way ticket to gravel enlightenment.

This Crux Expert comes spec'd with all-new SRAM Rival XPLR AXS for effortless braking, lighter weight, with massive 13 speed gear range, lightweight and durable Roval Terra C Disc wheels, and 2Bliss Ready, 700x40mm Pathfinder Pro tires that hookup over nasty terrain.

Lightest: 725g S-Works 12r and 825g 10r frames. We took the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over nightmarish terrain, and weighs less than a full bottle in your cage.
Capable: 47c/650b x 2.1” tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine, at full gas.
Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux’s iconic history in ‘cross.

❯ ❯ ❯ SPECIFICATIONS

Frameset
FRAME	Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension
FORK	S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Cockpit
SEATPOST	Roval Terra Carbon Seat Post, 20mm Offset
STEM	Specialized Pro SL, alloy, 4-bolt
SADDLE	Body Geometry Power Expert
TAPE	Supacaz Super Sticky Kush
HANDLEBARS	Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare
SEAT BINDER	Specialized Alloy, 30mm
Brakes
FRONT BRAKE	NEW SRAM Force AXS E1, hydraulic disc 160mm rotor
REAR BRAKE	NEW SRAM Force AXS E1, hydraulic disc 160mm rotor
Drivetrain
SHIFT LEVERS	NEW SRAM Force AXS E1 HRD
REAR DERAILLEUR	NEW SRAM Force XPLR AXS E1
CASSETTE	NEW SRAM Rival XPLR XG-1351, 13sp, 10-46t
CHAIN	NEW SRAM Force E1
CRANKSET	NEW SRAM Rival XPLR E1
BOTTOM BRACKET	SRAM DUB BSA
CHAINRINGS	40T
Wheels & Tires
FRONT WHEEL	Roval Terra C, 25mm inner width carbon rim, 32mm depth, DT 370 hub, 24h, DT Swiss Comp Race spokes
REAR WHEEL	Roval Terra C, 25mm inner width carbon rim, 32mm depth, DT 370 hub, 24h, DT Swiss Comp Race spokes
FRONT TIRE	Pathfinder 700x40, Tubeless Ready
REAR TIRE	Pathfinder 700x40, Tubeless Ready
INNER TUBES	Presta, 700X32-50mm
Product Details
PRODUCT ID	223489
Weight
WEIGHT	8.1 kg (17 lb, 13.7 oz)
WEIGHT SIZE	56

❯ ❯ ❯ GEOMETRY

	49	52	54	56	58	61
Crank Length	165	170	172.5	172.5	175	175
Handlebar Width	380	400	420	420	440	440
Stem Length	70	80	90	100	110	110
Saddle Width	155	155	143	143	143	143
Seatpost Length	330	330	330	380	380	380
Stack	530	547	560	578	598	621
Reach	375	382	388	397	405	415
Head Tube Length	100	115	130	147	167	190
Head Tube Angle	70.5	71.25	71.5	72	72.25	72.5
BB Height	284	284	286	286	286	286
BB Drop	74	74	72	72	72	72
Trail	74	69	67	64	62	60
Fork Length, Full	401	401	401	401	401	401
Fork Rake/Offset	50	50	50	50	50	50
Front Center	594	600	608	618	630	644
Chainstay Length	425	425	425	425	425	425
Wheelbase	1008	1014	1023	1033	1045	1059
Top Tube Length, Horizontal	512	539	549	568	582	599
Bike Standover Height	749	772	794	816	841	866
Seat Tube Length	466	496	521	546	576	606
Seat Tube Angle	75.5	74	74	73.5	73.5	73.5

❯ ❯ ❯ BUYING A BIKE

All bikes purchased from iRIDE will have been pre-assembled by our mechanics and test ridden. You will also receive a multi point checklist of all the safety checks and bike build elements we work through to ensure you bike is correctly assembled, and then tested so that it runs as it should. Bikes being sent to a customer who is unable to collect it from iRIDE, will have it boxed, wheels, saddle and bars generally off and re-packaged.

The delivery of bikes will be organized once a freight fee can be determined based on weight and delivery location.

Assembly should take no longer than 10-20 minutes. It is recommended that a skilled mechanic assemble, or check the bike. If possible your local bike shop is likely best placed to do this from a safety perspective to ensure all is as it should be. If a rider is having any issues we can hook up an online video chat, or talk over the phone. If this service is required email us at workshop@iride.net.nz to organise a time that suits all parties.
