SKU 91423-3056
$8,900.00 - $8,900.00
$8,900.00
$8,900.00 - $8,900.00
$8,900.00

Interested in this bike? Please email us or use the ENQUIRY FORM below to check your size and availability.

The bike may be available from the supplier if not in-store.

WE CAN ORGANISE DELIVERY OF BIKES NATIONWIDE.

NOTE: Afterpay is unavailable on bike purchases.

Choose a Color
Choose a Size
ENQUIRY

The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tire clearance and performance gravel geometry. It’s not just the ultimate expression of gravel performance, it’s your one-way ticket to gravel enlightenment.

This Crux Expert comes spec'd with an intuitive and crisp-shifting SRAM Rival eTap AXS hydraulic disc groupset, incredibly tough Roval Terra C Disc wheels, and 2Bliss Ready, 700x38mm Pathfinder Pro tires that hookup over nasty terrain.

  • Lightest: 725g S-Works 12r and 825g 10r frames. We took the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over nightmarish terrain, and weighs less than a full bottle in your cage.
  • Capable: 47c/650b x 2.1” tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine, at full gas.
  • Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux’s iconic history in ‘cross.

<div class="tech-specs">
<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc</p>
</div>

<div class="spec-item">
<p class="label">Seat Binder</p>
<p class="value">Specialized Alloy, 30mm</p>
</div>
</div>

<div class="spec-section">
<h4>Suspension</h4>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">FACT 12R Carbon, 12x100mm thru-axle, flat-mount disc</p>
</div>
</div>

<div class="spec-section">
<h4>Brakes</h4>

<div class="spec-item">
<p class="label">Front Brake</p>
<p class="value">SRAM Rival eTAP AXS, hydraulic disc</p>
</div>

<div class="spec-item">
<p class="label">Rear Brake</p>
<p class="value">SRAM Rival eTAP AXS, hydraulic disc</p>
</div>
</div>

<div class="spec-section">
<h4>Drivetrain</h4>

<div class="spec-item">
<p class="label">Shift Levers</p>
<p class="value">SRAM Rival eTAP AXS</p>
</div>

<div class="spec-item">
<p class="label">Rear Derailleur</p>
<p class="value">SRAM Rival XPLR eTap AXS</p>
</div>

<div class="spec-item">
<p class="label">Crankset</p>
<p class="value">SRAM Rival 1x</p>
</div>

<div class="spec-item">
<p class="label">Chainrings</p>
<p class="value">40T</p>
</div>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">SRAM DUB BSA</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">SRAM XPLR, XG-1251, 12-speed, 10-44t</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">SRAM Rival 12-speed</p>
</div>
</div>

<div class="spec-section">
<h4>Wheels &amp; Tires</h4>

<div class="spec-item">
<p class="label">Front Wheel</p>
<p class="value">Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 hub, 24h, DT Swiss Comp Race spokes</p>
</div>

<div class="spec-item">
<p class="label">Rear Wheel</p>
<p class="value">Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 hub, 24h, DT Swiss Comp Race spokes</p>
</div>

<div class="spec-item">
<p class="label">Front Tire</p>
<p class="value">Pathfinder Pro 2BR, Tan Sidewall, 700x38</p>
</div>

<div class="spec-item">
<p class="label">Rear Tire</p>
<p class="value">Pathfinder Pro 2BR, Tan Sidewall, 700x38</p>
</div>

<div class="spec-item">
<p class="label">Inner Tubes</p>
<p class="value">Standard 40mm SV 700x32-50</p>
</div>
</div>

<div class="spec-section">
<h4>Cockpit</h4>

<div class="spec-item">
<p class="label">Handlebars</p>
<p class="value">Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12º flare</p>
</div>

<div class="spec-item">
<p class="label">Stem</p>
<p class="value">Specialized Pro SL, alloy, 4-bolt, 6-degree rise</p>
</div>

<div class="spec-item">
<p class="label">Tape</p>
<p class="value">Supacaz Super Sticky Kush</p>
</div>

<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">Body Geometry Power Expert, titanium rails</p>
</div>

<div class="spec-item">
<p class="label">SeatPost</p>
<p class="value">Roval Terra Carbon Seat Post, 20mm Offset</p>
</div>
</div>

<div class="spec-section">
<h4>Weight</h4>

<div class="spec-item">
<p class="label">Weight</p>
<p class="value">8.16kg (17 lb, 15.8 oz)</p>
</div>

<div class="spec-item">
<p class="label">Weight Size</p>
<p class="value">56</p>
</div>
</div>

<p class="note">* Specifications are subject to change without notice.</p>
</div>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col"></th>
<th>49</th>
<th>52</th>
<th>54</th>
<th>56</th>
<th>58</th>
<th>61</th>
</tr>
</thead>

<tbody>
<tr>
<th class="sticky-col">Crank Length</th>
<td>165mm</td><td>170mm</td><td>172.5mm</td><td>172.5mm</td><td>175mm</td><td>175mm</td>
</tr>
<tr>
<th class="sticky-col">Handlebar Width</th>
<td>380mm</td><td>400mm</td><td>420mm</td><td>420mm</td><td>440mm</td><td>440mm</td>
</tr>
<tr>
<th class="sticky-col">Stem Length</th>
<td>70mm</td><td>80mm</td><td>90mm</td><td>100mm</td><td>110mm</td><td>110mm</td>
</tr>
<tr>
<th class="sticky-col">Saddle Width</th>
<td>155mm</td><td>155mm</td><td>143mm</td><td>143mm</td><td>143mm</td><td>143mm</td>
</tr>
<tr>
<th class="sticky-col">Seatpost Length</th>
<td>330mm</td><td>330mm</td><td>330mm</td><td>380mm</td><td>380mm</td><td>380mm</td>
</tr>
<tr>
<th class="sticky-col">Wheelbase</th>
<td>1008mm</td><td>1014mm</td><td>1023mm</td><td>1033mm</td><td>1045mm</td><td>1059mm</td>
</tr>
<tr>
<th class="sticky-col">Chainstay Length</th>
<td>425mm</td><td>425mm</td><td>425mm</td><td>425mm</td><td>425mm</td><td>425mm</td>
</tr>
<tr>
<th class="sticky-col">Head Tube Length</th>
<td>100mm</td><td>115mm</td><td>130mm</td><td>147mm</td><td>167mm</td><td>190mm</td>
</tr>
<tr>
<th class="sticky-col">Head Tube Angle</th>
<td>70.5°</td><td>71.25°</td><td>71.5°</td><td>72°</td><td>72.25°</td><td>72.5°</td>
</tr>
<tr>
<th class="sticky-col">BB Height</th>
<td>284mm</td><td>284mm</td><td>286mm</td><td>286mm</td><td>286mm</td><td>286mm</td>
</tr>
<tr>
<th class="sticky-col">Fork Rake/Offset</th>
<td>50mm</td><td>50mm</td><td>50mm</td><td>50mm</td><td>50mm</td><td>50mm</td>
</tr>
<tr>
<th class="sticky-col">Seat Tube Length</th>
<td>466mm</td><td>496mm</td><td>521mm</td><td>546mm</td><td>576mm</td><td>606mm</td>
</tr>
<tr>
<th class="sticky-col">Stack</th>
<td>530mm</td><td>547mm</td><td>560mm</td><td>578mm</td><td>598mm</td><td>621mm</td>
</tr>
<tr>
<th class="sticky-col">Fork Length, Full</th>
<td>401mm</td><td>401mm</td><td>401mm</td><td>401mm</td><td>401mm</td><td>401mm</td>
</tr>
<tr>
<th class="sticky-col">Front Center</th>
<td>594mm</td><td>600mm</td><td>608mm</td><td>618mm</td><td>630mm</td><td>644mm</td>
</tr>
<tr>
<th class="sticky-col">Reach</th>
<td>375mm</td><td>382mm</td><td>388mm</td><td>397mm</td><td>405mm</td><td>415mm</td>
</tr>
<tr>
<th class="sticky-col">Seat Tube Angle</th>
<td>75.5°</td><td>74°</td><td>74°</td><td>73.5°</td><td>73.5°</td><td>73.5°</td>
</tr>
<tr>
<th class="sticky-col">BB Drop</th>
<td>74mm</td><td>74mm</td><td>72mm</td><td>72mm</td><td>72mm</td><td>72mm</td>
</tr>
<tr>
<th class="sticky-col">Trail</th>
<td>74mm</td><td>69mm</td><td>67mm</td><td>64mm</td><td>62mm</td><td>60mm</td>
</tr>
<tr>
<th class="sticky-col">Top Tube Length, Horizontal</th>
<td>512mm</td><td>539mm</td><td>549mm</td><td>568mm</td><td>582mm</td><td>599mm</td>
</tr>
<tr>
<th class="sticky-col">Bike Standover Height</th>
<td>749mm</td><td>772mm</td><td>794mm</td><td>816mm</td><td>841mm</td><td>866mm</td>
</tr>
</tbody>
</table>
</div>
</div>
