The new Tarmac is designed to go fast, there's no if's, and's, or but's about that—but it represents so much more than just aerodynamic prowess. With a light-weight, Rider-First Engineered™ frame, it delivers the best-possible ride characteristics, no matter the size. So no matter what you have planned for your new Tarmac, its ready to help you achieve your goals—PRs, KOMs, or podium top-steps. One bike to rule them all.
With the new Shimano 105 Mechanical 12-speed group, along with some fast rolling tires in the Turbo Pro 700x26mm tires, this new Tarmac delivers performance at a more palatable price point.
- While aerodynamics were paramount to the Tarmac’s development, and to the development of all of our race bikes, weight was the co-pilot on this optimal race bike journey. Previously “aero bikes” always compromised in the weight department—the more drag you reduced, the more weight you gained. With the new Tarmac, our design philosophy was to keep it at, or below, the UCI weight limit out of the box, with no sacrifices to aerodynamics. And with the help of the FreeFoil Shape Library, tools like isotopic FEA analysis, and some engineering wizardry by the best engineers in the industry, we delivered a Fact 9r frame that weighs a mere 1010 grams, without giving up a gram of aero, stiffness or ride quality.
- Continuing our quest to develop the perfect race bike, we used our Rider-First Engineered™ philosophy to ensure that the new Tarmac is the most balanced, best handling Tarmac yet—no matter the size. With an army of the world’s best test riders from our three World Tour Teams — Boels-Dolmans, Deceuninck-Quick-Step, and Bora-hansgrohe — we made changes to the Tarmac based on their thousands of kilometers on the road. We balanced the ride quality between the front and rear end, so even the longest days in the saddle continue to be comfortable—all without giving up anything to the Tarmac’s legendary handling and race-winning snappiness.
- Building on the learnings from the Venge, the new Tarmac utilizes simple integration to create a clean, fast cockpit that’s easy to live with. We’ve improved the routing for any configuration — mechanical shifting, traditional stems, round bars, etc. — all while keeping its aerodynamic attributes. These same traits also make the new Tarmac easy to work on and easy to travel with. It’s a win-win.
Frameset FRAME Tarmac SL7 FACT 9r Carbon, Rider First Engineered™, Win Tunnel Engineered, Clean Routing, Threaded BB, 12x142mm thru-axle, flat-mount disc Suspension FORK FACT Carbon, 12x100mm thru-axle, flat-mount disc Cockpit SEATPOST 2021 S-Works Tarmac Carbon seat post, FACT Carbon, 20mm offset STEM Tarmac integrated stem, 6-degree SADDLE Body Geometry Power Sport, steel rails TAPE Supacaz Super Sticky Kush HANDLEBARS Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp SEAT BINDER Tarmac integrated wedge Brakes FRONT BRAKE Shimano 105, Hydraulic Disc REAR BRAKE Shimano 105, Hydraulic Disc Drivetrain SHIFT LEVERS Shimano 105, 12 speed Mechanical FRONT DERAILLEUR Shimano 105, Braze-on REAR DERAILLEUR Shimano 105, 12 speed Mechanical CASSETTE Shimano 105, 12-speed, 11-34t CHAIN Shimano SLX M7100, 12-speed w/ quick link CRANKSET Shimano 105, 12-speed BOTTOM BRACKET Shimano Threaded BSA BB CHAINRINGS 52/36T Wheels & Tires FRONT WHEEL DT R470 Disc REAR WHEEL DT R470 Disc FRONT TIRE Turbo Pro, 700x26 REAR TIRE Turbo Pro, 700x26 INNER TUBES Presta Valve Standard, 48mm valves Product Details PRODUCT ID 221542 Weight WEIGHT 8.25kg (18 lb, 3 oz) WEIGHT SIZE 56 * Specifications are subject to change without notice
44 49 52 54 56 58 61 Crank Length 165 165 170 172.5 172.5 175 175 Handlebar Width 360 380 400 420 420 440 440 Stem Length 70 80 90 100 100 110 110 Saddle Width 155 155 155 143 143 143 143 Seatpost Length 300 300 300 380 380 380 380 Frame Stack 491 504 517 534 555 581 602 Frame Reach 369 378 383 387 398 405 411 Stack to Stem 509 522 535 552 573 599 620 Reach to Stem 381 393 400 406 363 372 377 Head Tube Length 93 102 113 131 151 178 198 Head Tube Angle 70.5 71.75 72.5 73 73.5 73.5 74 BB Height 266 266 266 268 268 268 268 BB Drop 72 72 72 74 74 74 72 Trail 71 63 58 58 55 55 52 Fork Length, Full 366 366 366 366 366 366 366 Fork Rake/Offset 47 47 47 44 44 44 44 Front Center 572 574 577 579 592 606 613 Chainstay Length 410 410 410 410 410 410 410 Wheelbase 1006 1013 970 973 975 978 991 Top Tube Length, Horizontal 496 509 531 541 563 577 595 Bike Standover Height 723 735 746 768 786 808 834 Seat Tube Length 435 447 458 475 496 517 547 Seat Tube Angle 75.5 75.5 74 74 73.5 73.5 73 All bikes purchased from iRIDE will have been pre-assembled by our mechanics and test ridden. You will also receive a multi point checklist of all the safety checks and bike build elements we work through to ensure you bike is correctly assembled, and then tested so that it runs as it should. Bikes being sent to a customer who is unable to collect it from iRIDE, will have it boxed, wheels, saddle and bars generally off and re-packaged.
The delivery of bikes will be organized once a freight fee can be determined based on weight and delivery location.
Assembly should take no longer than 10-20 minutes. It is recommended that a skilled mechanic assemble, or check the bike. If possible your local bike shop is likely best placed to do this from a safety perspective to ensure all is as it should be. If a rider is having any issues we can hook up an online video chat, or talk over the phone. If this service is required email us at workshop@iride.net.nz to organise a time that suits all parties.
