<!-- Geometry image (static, centred) -->
<div class="curve-geo-static">
<img
src="https://cdn.shopify.com/s/files/1/0089/4972/7298/files/Curve_-_GXR_AKA_Kevin_of_Titanium_Geo.jpg?v=1768439450"
alt="Curve Geometry Diagram"
loading="lazy"
/>

<div class="curve-geo-notes">
<p>BB and standover heights based on: 700 x 42c tyres.</p>
</div>
</div>

<style>
.curve-geo-static {
width: 100%;
display: flex;
flex-direction: column;
align-items: center;
margin: 16px 0 24px;
}

.curve-geo-static img {
max-width: 980px;
width: 100%;
height: auto;
}

.curve-geo-notes {
max-width: 980px;
width: 100%;
margin-top: 8px;
font-size: 12.5px;
line-height: 1.4;
color: #666;
}

.curve-geo-notes p {
margin: 2px 0;
}
</style>


<script>
(function () {
const wrap = document.querySelector('.curve-geo');
if (!wrap) return;

const thumb = wrap.querySelector('.curve-geo__thumb');
const dialog = wrap.querySelector('.curve-geo__lightbox');
const closeBtn = wrap.querySelector('.curve-geo__close');

if (!thumb || !dialog || !closeBtn) return;

thumb.addEventListener('click', () => dialog.showModal());
closeBtn.addEventListener('click', () => dialog.close());

dialog.addEventListener('click', (e) => {
// Close when clicking backdrop (but not when clicking the image)
if (e.target === dialog) dialog.close();
});

document.addEventListener('keydown', (e) => {
if (e.key === 'Escape' && dialog.open) dialog.close();
});
})();
</script>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col">SIZE</th>
<th>XXS</th>
<th>XS</th>
<th>SM</th>
<th>MD</th>
<th>LG</th>
<th>XL</th>
<th>XXL</th>
</tr>
</thead>

<tbody>
<tr>
<th class="sticky-col">Rider Height (cm)</th>
<td>148–157</td>
<td>154–163</td>
<td>160–170</td>
<td>166–178</td>
<td>175–187</td>
<td>184–194</td>
<td>190–200</td>
</tr>

<tr>
<th class="sticky-col">Saddle Height (mm)</th>
<td>610–670</td>
<td>650–705</td>
<td>690–735</td>
<td>720–765</td>
<td>745–795</td>
<td>775–825</td>
<td>805–865</td>
</tr>

<tr>
<th class="sticky-col">Effective Top Tube (A)</th>
<td>529</td><td>541</td><td>554</td><td>564</td><td>574</td><td>589</td><td>604</td>
</tr>

<tr>
<th class="sticky-col">Seat Tube Length (B)</th>
<td>460</td><td>500</td><td>530</td><td>560</td><td>580</td><td>595</td><td>615</td>
</tr>

<tr>
<th class="sticky-col">Seat Tube Angle (C)</th>
<td>73°</td><td>73°</td><td>73°</td><td>73°</td><td>73°</td><td>73°</td><td>73°</td>
</tr>

<tr>
<th class="sticky-col">Head Tube Angle (D)</th>
<td>71°</td><td>71°</td><td>71.5°</td><td>71.5°</td><td>72°</td><td>72°</td><td>72°</td>
</tr>

<tr>
<th class="sticky-col">Chainstay (E)</th>
<td>432</td><td>432</td><td>432</td><td>432</td><td>432</td><td>432</td><td>435</td>
</tr>

<tr>
<th class="sticky-col">BB Drop (F)</th>
<td>72</td><td>70</td><td>70</td><td>70</td><td>68</td><td>68</td><td>68</td>
</tr>

<tr>
<th class="sticky-col">BB Height</th>
<td>274</td><td>276</td><td>276</td><td>276</td><td>278</td><td>278</td><td>278</td>
</tr>

<tr>
<th class="sticky-col">Wheelbase (G)</th>
<td>1005</td><td>1018</td><td>1027</td><td>1037</td><td>1044</td><td>1059</td><td>1078</td>
</tr>

<tr>
<th class="sticky-col">Head Tube Length (H)</th>
<td>110</td><td>115</td><td>125</td><td>136</td><td>150</td><td>170</td><td>210</td>
</tr>

<tr>
<th class="sticky-col">Reach (I)</th>
<td>362</td><td>373</td><td>383</td><td>389</td><td>396</td><td>405</td><td>408</td>
</tr>

<tr>
<th class="sticky-col">Stack (J)</th>
<td>547</td><td>550</td><td>561</td><td>572</td><td>585</td><td>604</td><td>642</td>
</tr>

<tr>
<th class="sticky-col">Front Centre (K)</th>
<td>584</td><td>596</td><td>605</td><td>615</td><td>621</td><td>636</td><td>652</td>
</tr>

<tr>
<th class="sticky-col">Standover (L)</th>
<td>743</td><td>765</td><td>784</td><td>804</td><td>822</td><td>839</td><td>867</td>
</tr>
</tbody>
</table>
</div>
</div>
