Where It All Started

The Belgie is affectionately named after Melbourne's infamous "Belgie Ride,” a short, sharp, mixed terrain shop ride that often resembles a CX race rather than a road ride.

In 2015, the Belgie was introduced to the world when Jesse Carlsson raced across the US, winning the 6,800 km Trans Am Bike Race by over 500 km.

Since then, the Belgie has won crits, raced nationals, and is the bike chosen by legendary Belgian Kristof Allegaert, arguably one of the world's fastest endurance cyclists.

The Belgie DISC is a combined version of the original Belgie and our Belgie Air based on feedback and real-life testing.

Compared to it's Predecessor, What's Different?

We've straightened out the seat stays and removed the old ‘brake bridge’ for a new sleeker and lighter rear triangle. This means better tyre clearance, up to 33 mm. Upfront, the tapered head tube is taken straight from our Belgie AIR and utilises an integrated headset for some gram shedding and a sleeker finish.

A Size for Everyone

Are you an ‘extra medium’ or in-between size? Check out our sizing and geometry chart below and see that we've introduced more sizes to ensure your Belgie is the perfect fit.

Mechanical versus Electric

Thanks to some improvements in engineering, the Belgie frame is now compatible with both electronic and mechanical gear systems. So you can now have your pick of eTap, Di2, or standard mechanical options.

Travel in Comfort

At the core of each frame is a 3AL - 2.5V Grade 9 Aerospace grade titanium tube-set. This grade is optimal for bicycle frames and chosen for its stiffness, compliance, and durability balance. Titanium absorbs road noise without compromising on performance. There’s no buzzy feedback; it’s smooth as silk and very compliant so that you can spend more time on the bike.

Want to Carry More?

With a wide range of frame and fork mounted rack systems on the market, and with more appearing every week, it is important to understand which rack systems are compatible with your Curve frame and fork, and how to mount them correctly in order to ensure safe riding, avoid damage and voiding your warranty. Before mounting a rack, we strongly recommend you get in touch with us to confirm compatibility and the correct mounting procedure. This will minimise the risk of injury, product damage and voiding your warranty. Your local Curve dealer, or the team at Curve HQ, can also help you select a rack system and mount it to your bike for you.

<div class="tech-specs">

<!-- FRAMESET -->
<div class="spec-section">
<h4>Frameset</h4>

<div class="spec-item">
<p class="label">Frame</p>
<p class="value">
Titanium Curve Belgie DISC<br>
Approx. 1630g (Size 56cm)
</p>
</div>

<div class="spec-item">
<p class="label">Fork</p>
<p class="value">
Curve Race 370 – Full Carbon (Black)<br>
Maximum tyre clearance: 33mm
</p>
</div>

<div class="spec-item">
<p class="label">Headset</p>
<p class="value">Curve Integrated 42 / 52mm semi-internal</p>
</div>

<div class="spec-item">
<p class="label">Seat Clamp</p>
<p class="value">Curve Alloy 31.8mm</p>
</div>

<div class="spec-item">
<p class="label">Other</p>
<p class="value">
Curve Cocky Headbadge<br>
12mm front &amp; rear axles<br>
Spare rear derailleur hanger
</p>
</div>
</div>

<!-- GROUPSET OPTIONS -->
<div class="spec-section">
<h4>Groupset Options</h4>

<!-- SRAM RED -->
<div class="spec-item">
<p class="label">Option</p>
<p class="value"><strong>SRAM Red AXS eTap 2x12</strong></p>
</div>

<div class="spec-item">
<p class="label">Shifter / Levers</p>
<p class="value">Red AXS 2x12-speed – LHR / RHF</p>
</div>

<div class="spec-item">
<p class="label">Brakes</p>
<p class="value">
Red AXS Flat Mount Disc<br>
CLX-R CentreLock rotors – 160mm
</p>
</div>

<div class="spec-item">
<p class="label">Crank</p>
<p class="value">
Red Power Meter DUB – 48/35T<br>
48–50cm: 165mm | 52–55cm: 170mm | 56–61cm: 175mm
</p>
</div>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">Curve T47 DUB External</p>
</div>

<div class="spec-item">
<p class="label">Derailleurs (Front &amp; Rear)</p>
<p class="value">Red AXS 2x12-speed (RD max 33T)</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">XG-1290, 10–33T, 12-speed</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">Red, 12-speed</p>
</div>

<hr>

<!-- SRAM FORCE -->
<div class="spec-item">
<p class="label">Option</p>
<p class="value"><strong>SRAM Force AXS eTap 2x12</strong></p>
</div>

<div class="spec-item">
<p class="label">Shifter / Levers</p>
<p class="value">Force AXS 2x12-speed – LHR / RHF</p>
</div>

<div class="spec-item">
<p class="label">Brakes</p>
<p class="value">
Force AXS Flat Mount Disc<br>
CLX-R CentreLock rotors – 160mm
</p>
</div>

<div class="spec-item">
<p class="label">Crank</p>
<p class="value">
Force DUB – 48/35T<br>
48–50cm: 165mm | 52–55cm: 170mm | 56–61cm: 175mm
</p>
</div>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">Curve T47 DUB External</p>
</div>

<div class="spec-item">
<p class="label">Derailleurs (Front &amp; Rear)</p>
<p class="value">Force AXS 2x12-speed (RD max 36T)</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">XG-1270, 10–36T, 12-speed</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">Force, 12-speed</p>
</div>

<hr>

<!-- SRAM RIVAL -->
<div class="spec-item">
<p class="label">Option</p>
<p class="value"><strong>SRAM Rival AXS 2x12</strong></p>
</div>

<div class="spec-item">
<p class="label">Shifter / Levers</p>
<p class="value">Rival AXS 2x12-speed – LHR / RHF</p>
</div>

<div class="spec-item">
<p class="label">Brakes</p>
<p class="value">
Rival Flat Mount Disc<br>
CentreLock rotors – 160mm
</p>
</div>

<div class="spec-item">
<p class="label">Crank</p>
<p class="value">
Rival D1 DUB – 48/35T<br>
48–50cm: 165mm | 52–55cm: 170mm | 56–61cm: 175mm
</p>
</div>

<div class="spec-item">
<p class="label">Bottom Bracket</p>
<p class="value">Curve T47 DUB External</p>
</div>

<div class="spec-item">
<p class="label">Derailleurs (Front &amp; Rear)</p>
<p class="value">Rival AXS D1, 12-speed (RD max 36T)</p>
</div>

<div class="spec-item">
<p class="label">Cassette</p>
<p class="value">XG-1250 D1, 10–36T, 12-speed</p>
</div>

<div class="spec-item">
<p class="label">Chain</p>
<p class="value">Rival, 12-speed</p>
</div>
</div>

<!-- WHEELS -->
<div class="spec-section">
<h4>Wheels</h4>

<div class="spec-item">
<p class="label">Wheelset</p>
<p class="value">
Curve G4T – 700C (45mm depth)<br>
Carbon all-road wheels
</p>
</div>

<div class="spec-item">
<p class="label">Rims</p>
<p class="value">21mm internal / 28mm external / 35 or 45mm deep</p>
</div>

<div class="spec-item">
<p class="label">Hubs</p>
<p class="value">DT Swiss 350, 24H, CentreLock</p>
</div>

<div class="spec-item">
<p class="label">Spokes &amp; Nipples</p>
<p class="value">Sapim CX-Ray spokes with brass nipples</p>
</div>

<div class="spec-item">
<p class="label">Axle Spacing</p>
<p class="value">12 x 100mm front / 12 x 142mm rear</p>
</div>
</div>

<!-- FINISHING KIT -->
<div class="spec-section">
<h4>Finishing Kit</h4>

<div class="spec-item">
<p class="label">Handlebars</p>
<p class="value">Zipp Service Course SL Beyond Black</p>
</div>

<div class="spec-item">
<p class="label">Stem</p>
<p class="value">Zipp Service Course SL (Service Course with Rival builds)</p>
</div>

<div class="spec-item">
<p class="label">Seatpost</p>
<p class="value">Zipp Service Course SL 0°, 27.2mm (SC with Rival builds)</p>
</div>

<div class="spec-item">
<p class="label">Saddle</p>
<p class="value">Fi’zi:k Vento Argo</p>
</div>

<div class="spec-item">
<p class="label">Tyres</p>
<p class="value">Rubino Pro TLR – 700 x 30c</p>
</div>

<div class="spec-item">
<p class="label">Bar Tape</p>
<p class="value">Curve Black Anti-Shock</p>
</div>
</div>

<p class="note">*Specifications subject to change according to availability</p>

</div>

<!-- Geometry image (static, centred) -->
<div class="curve-geo-static">
<img
src="https://cdn.shopify.com/s/files/1/0089/4972/7298/files/Belgie_Disc_WebGeo.jpg?v=1768440394"
alt="Curve Belgie DISC V3 Geometry Diagram"
loading="lazy"
/>

<div class="curve-geo-notes">
<p>Dimensions based on: 700 x 30c tyres.</p>
<p>Standover height: Measured 60mm in front of BB.</p>
</div>
</div>

<style>
.curve-geo-static {
width: 100%;
display: flex;
flex-direction: column;
align-items: center;
margin: 16px 0 24px;
}

.curve-geo-static img {
max-width: 980px;
width: 100%;
height: auto;
}

.curve-geo-notes {
max-width: 980px;
width: 100%;
margin-top: 8px;
font-size: 12.5px;
line-height: 1.4;
color: #666;
}

.curve-geo-notes p {
margin: 2px 0;
}
</style>

<div class="bike-geometry-table">
<div class="bike-geometry-table__scroller">
<table>
<thead>
<tr>
<th class="sticky-col">SIZE</th>
<th>48</th>
<th>50</th>
<th>52</th>
<th>53</th>
<th>54</th>
<th>55</th>
<th>56</th>
<th>58</th>
<th>61</th>
</tr>
</thead>

<tbody>
<tr>
<th class="sticky-col">Rider Height (cm)</th>
<td>149–157</td>
<td>154–162</td>
<td>160–168</td>
<td>166–173</td>
<td>170–176</td>
<td>173–180</td>
<td>178–185</td>
<td>183–190</td>
<td>188–196</td>
</tr>

<tr>
<th class="sticky-col">Saddle Height (mm)</th>
<td>620–670</td>
<td>655–705</td>
<td>690–730</td>
<td>705–745</td>
<td>720–750</td>
<td>730–765</td>
<td>750–790</td>
<td>775–825</td>
<td>810–860</td>
</tr>

<tr>
<th class="sticky-col">Effective Top Tube (A)</th>
<td>514</td><td>524</td><td>534</td><td>544</td><td>554</td><td>564</td><td>574</td><td>595</td><td>615</td>
</tr>

<tr>
<th class="sticky-col">Seat Tube Length (B)</th>
<td>485</td><td>505</td><td>525</td><td>535</td><td>545</td><td>555</td><td>570</td><td>590</td><td>625</td>
</tr>

<tr>
<th class="sticky-col">Seat Tube Angle (C)</th>
<td>74°</td><td>74°</td><td>73.5°</td><td>73.5°</td><td>73.5°</td><td>73.5°</td><td>73.5°</td><td>73°</td><td>73°</td>
</tr>

<tr>
<th class="sticky-col">Head Tube Angle (D)</th>
<td>71.5°</td><td>72°</td><td>72.5°</td><td>72.5°</td><td>72.5°</td><td>72.5°</td><td>72.5°</td><td>73°</td><td>73°</td>
</tr>

<tr>
<th class="sticky-col">Chainstay (E)</th>
<td>410</td><td>410</td><td>410</td><td>410</td><td>412</td><td>412</td><td>412</td><td>415</td><td>415</td>
</tr>

<tr>
<th class="sticky-col">BB Drop (F)</th>
<td>75</td><td>75</td><td>75</td><td>72</td><td>72</td><td>72</td><td>72</td><td>70</td><td>70</td>
</tr>

<tr>
<th class="sticky-col">BB Height</th>
<td>267</td><td>267</td><td>267</td><td>270</td><td>270</td><td>270</td><td>270</td><td>272</td><td>272</td>
</tr>

<tr>
<th class="sticky-col">Wheelbase (G)</th>
<td>962</td><td>968</td><td>969</td><td>981</td><td>993</td><td>1003</td><td>1013</td><td>1028</td><td>1048</td>
</tr>

<tr>
<th class="sticky-col">Head Tube Length (H)</th>
<td>110</td><td>115</td><td>120</td><td>130</td><td>140</td><td>150</td><td>160</td><td>190</td><td>230</td>
</tr>

<tr>
<th class="sticky-col">Reach (I)</th>
<td>366</td><td>374</td><td>378</td><td>386</td><td>393</td><td>400</td><td>408</td><td>414</td><td>422</td>
</tr>

<tr>
<th class="sticky-col">Stack (J)</th>
<td>516</td><td>522</td><td>528</td><td>535</td><td>545</td><td>554</td><td>564</td><td>592</td><td>630</td>
</tr>

<tr>
<th class="sticky-col">Front Centre (K)</th>
<td>563</td><td>569</td><td>571</td><td>581</td><td>592</td><td>602</td><td>612</td><td>623</td><td>642</td>
</tr>

<tr>
<th class="sticky-col">Standover (L)</th>
<td>732</td><td>745</td><td>757</td><td>768</td><td>777</td><td>787</td><td>799</td><td>824</td><td>860</td>
</tr>

<tr>
<th class="sticky-col">Fork Length (AC)</th>
<td colspan="9">370</td>
</tr>

<tr>
<th class="sticky-col">Fork Offset (R)</th>
<td colspan="9">45</td>
</tr>
</tbody>
</table>
</div>
</div>
