In 2019, Áspero took the gravel world by storm, heralding a “new era of speed in gravel.” Fun, but flat out. The new Áspero remains true to its original brief, but with some improvements: a threaded BB shell, neater cable routing, and a UDH-compatible derailleur hanger for those who want to use SRAM’s Transmission drivetrains. And it’s more aero, of course. In the case of Áspero, aerodynamic performance is less about pure speed as a result of drag reduction, and more about conservation of energy. After a big day in a headwind, the three watts saved over the previous Aspero might add up to one less energy gel your stomach has to digest—WORTH IT.
In addition to the drag reduction, we also dropped the seat stays to give a bit more compliance out back, and reduced front-end stiffness slightly to make the last hours of a long race less painful. Between those dropped seat stays, we added in a bit more clearance for mud, too, taking what we learned from R5-CX (and the Unbound mudfest in 2023). It’s a lot of seemingly small improvements, but they add up to a lot. The result is a bike that feels a lot like the original Áspero, but is faster, more comfortable, and more versatile.
THREADED BOTTOM BRACKET
Aspero uses the asymmetrical T47a threaded bottom bracket we pioneered on R5-CX. It’s a simple, rider-serviceable interface that allows us to deliver the benefits of BBRight in a more user-friendly form.
UNIVERSAL DERAILLEUR HANGER
We used SRAM’s Universal Derailleur Hanger (UDH) standard on the new Aspero. It’s ideal if you want to live your best ‘business in the front, party in the back’ life with one of SRAM’s Transmission drivetrains today, and ensures compatibility for future drivetrain developments.
INTERNAL CABLE ROUTING
Aspero shares the same bearing dimensions as R5, Soloist, R5-CX, and Caledonia, which means you can use any combination of bearing caps and stems. Want a super-racy, fully-internal look? Grab the ST31 and HB13 from R5.
Colour Black/Charcoal, Marigold Color Finish Gloss Fork Cervélo All-Carbon, Tapered P Fork Headset FSA IS2 1-1/4, 45° x 45° / 1-3/8, 36° x 45° Seatpost Cervélo Alloy 27.2 Seatpost Sizing Size 48 - 0mm, Size 51 - 0mm, Size 54 - 0mm, Size 56 - 0mm, Size 58 - 0mm, Size 61 - 15mm Left Shifter/Brake Shimano GRX, RX610 Right Shifter/Brake Shimano GRX, RX610 Front Derailleur Shimano GRX, RX820 Rear Derailleur Shimano GRX, RX820 Brake Rotors Shimano RT66 6-Bolt Front Thru Axles Cervélo Aero Thru Axle Front, M12x1.5mm, 127mm length Rear Thru Axles Cervélo Aero Thru Axle Rear, M12x1.0mm, 169mm length Bottom Bracket FSA, T47 BBright for 24mm spindle Crankset Shimano GRX, RX610, 46/30T Crank Sizing Size 48 - 165mm SRAM, 170mm Shimano, Size 51 - 165mm SRAM, 170mm Shimano, Size 54 - 170mm, Size 56 - 170mm, Size 58 - 172.5mm, Size 61 - 172.5mm Handlebar Zipp Service Course 70 XPLR Alloy, 31.8mm clamp, 5 degree flare, 11 degree outsweep Handlebar Sizing Size 48 - 36cm, Size 51 - 38cm, Size 54 - 40cm, Size 56 - 40cm, Size 58 - 42cm, Size 61 - 42cm Stem Cervélo ST36 Alloy Stem Sizing Size 48 - 80mm, Size 51 - 80mm, Size 54 - 90mm, Size 56 - 90mm, Size 58 - 100mm, Size 61 - 100mm Saddle Cervélo Saddle Cassette Shimano HG710, 11-36T, 12-Speed Chain Shimano M7100 Front Wheel Alexrims GX7, 12x100mm, 24H, 25mm IW, 6 bolt, tubeless compatible Rear Wheel Alexrims GX7, 12x142mm, 24H, 25mm IW, HG freehub, 6 bolt, tubeless compatible Tire WTB Vulpine TCS Light Fast Rolling Dual DNA 60tpi 700x45c Max Tire Width 700c - 45mm / 650c - 47mm 48 51 54 56 58 61 Reach | mm 370 379 388 397 406 415 Stack | mm 505 530 555 580 605 630 Head Tube Angle 71° 71.5° 72° 72° 72° 72° Front Center | mm 577/582 587/592 597/602 614/619 631/637 648/654 Bottom Bracket Drop | mm 78.5 78.5 76 76 73.5 73.5 Head Tube Length | mm 83 107 133 159 188 214 Top Tube Length | mm 512 532 553 575 591 608 Seat Tube Angle 74.5° 74° 73.5° 73° 73° 73° Standover Height | mm 681 704 733 757 784 808 Trail | mm 62 62 62 62 62 62 Wheel Size 700C 700C 700C 700C 700C 700C Fork Offset | mm 52/57 49/54 46/51 46/51 46/51 46/51 Wheelbase | mm 990/995 999/1004 1010/1015 1028/1033 1046/1051 1063/1068 Chainstay Length | mm 425 425 425 425 425 425 All bikes purchased from iRIDE will have been pre-assembled by our mechanics and test ridden. You will also receive a multi point checklist of all the safety checks and bike build elements we work through to ensure you bike is correctly assembled, and then tested so that it runs as it should. Bikes being sent to a customer who is unable to collect it from iRIDE, will have it boxed, wheels, saddle and bars generally off and re-packaged.
The delivery of bikes will be organized once a freight fee can be determined based on weight and delivery location.
Assembly should take no longer than 10-20 minutes. It is recommended that a skilled mechanic assemble, or check the bike. If possible your local bike shop is likely best placed to do this from a safety perspective to ensure all is as it should be. If a rider is having any issues we can hook up an online video chat, or talk over the phone. If this service is required email us at workshop@iride.net.nz to organise a time that suits all parties.
