Specialized Stumpjumper 15 EVO Expert Di2

Specialized Stumpjumper 15 EVO Expert Di2

SKU 93326-3002
$0.00 - $0.00
$12,900.00
$12,900.00 - $12,900.00
$12,900.00
Colour: Gloss Nebula Metallic / Dolomite Metallic
Wheel Size: 29/27.5
Size: 29/27.5

ETA - Late OCT

One Bike to Rule All Trails

Capability, Control, Personalization



The all-new Stumpjumper 15 EVO obliterates every trade-off in the trail game. It’s the ‘Bike of the Year’ winning Stumpy 15 you know, turned up to 11—with a longer-travel 160mm FOX fork, external reservoir FOX FLOAT X shock, and a slacker headtube for next-level capability. Devour bumps like a big bike? Check. Short-travel control, playfulness, and efficiency? Double check. A heaping helping of personalization to make it perfect for the only rider who matters—you? Check, check, check.

At a Glance

Use

Trail

Frameset

FACT 11m carbon chassis w/ SWAT

Suspension

Front: 160mm FOX FLOAT 36 Performance Elite, GRIP X2
Rear: 145mm FOX FLOAT X GENIE Performance Elite

Drivetrain

Shimano XT Di2

Wheels

Traverse Alloy/DT Swiss 370

Weight

31lbs. 14.8oz.

Frameset
FRAME FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
SEAT BINDER Alloy, 38.6mm
SWAT Internal SWAT Downtube Storage
Suspension
REAR SHOCK FOX FLOAT X Performance Elite with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSC adjustment, LSR adjustment, 210x55mm
FORK FOX FLOAT 36 Performance Elite, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm Kabolt axle, 44mm offset, S1:150mm of travel, S2-S6:160mm of travel
Cockpit
SEATPOST PNW Loam Dropper, tool-less travel adjust, Range lever, 34.9, S1: 125mm, S2: 150mm, S3: 175mm, S4-S5: 200mm, S6: 225mm
STEM Alloy Trail Stem, 35mm bar bore
SADDLE Bridge Comp, Hollow Cr-mo rails S1-S2: 155mm, S3-S6:143mm
GRIPS Deity Lockjaw Grips
HANDLEBARS Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
Brakes
FRONT BRAKE Shimano Deore XT brake, 4 piston, Metal pad w/fin, 203mm rotor
REAR BRAKE Shimano Deore XT brake, 4 piston, Metal pad w/fin, S1-S2: 180mm, S3-S6: 203mm rotor
Drivetrain
SHIFT LEVERS Shimano XT Di2
REAR DERAILLEUR Shimano XT Di2, 12-speed
CASSETTE Shimano XT M8200, 12-speed, 10-51
CHAIN Shimano XT M8100, 12-speed w/ quick link
CRANKSET Shimano XT, 55mm chainline, 32T, S1-S3: 165mm, S4-S6: 170mm
BOTTOM BRACKET Shimano, BB-MT801, Threaded
Wheels & Tires
FRONT HUB Roval Traverse 29" Rim, hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370, 15x110mm, 28h, Sapim Force Spokes, 6 bolt
REAR HUB Roval Traverse Rim, hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370, 15x110mm, 28h, Sapim Force Spokes, 6 bolt
FRONT TIRE Butcher, GRID TRAIL casing, GRIPTON® T9 compound, TLR, 29X2.4
REAR TIRE Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
INNER TUBES Standard, Presta valve
Product Details
PRODUCT ID 291645
Weight
WEIGHT 14.48 kg (31 lb, 14.8 oz)
WEIGHT SIZE S4

* Specifications are subject to change without notice

S1S2S3S4S5S6
Crank Length165165165170170170
Handlebar Width780780800800800800
Stem Length404040404040
Saddle Width155155143143143143
Seatpost Length125150175200200225
Stack611621630644658671
Reach400420445470495525
Headtube Length95100110125140155
Headtube Angle646464646464
BB Height337340340340340340
BB Drop383535353535
Trail133134134134134134
Fork Length (full)561573573573573573
Fork Rake/Offset444444444444
Front Center724755785816848884
Chainstay Length430432435435445445
Wheelbase115311861217124912901327
Top-tube Length (horizontal)542574596625649678
Bike Standover Height738751745745745751
Seat Tube Length385385405425445465
Seat Tube Angle77.776.576.5767676
Saddle Height for Effective ST Angle825870645690735780
Max Seatpost Insertion245245255255285285
Min Seatpost Insertion808080808080

All bikes purchased from iRIDE will have been pre-assembled by our mechanics and test ridden. You will also receive a multi point checklist of all the safety checks and bike build elements we work through to ensure you bike is correctly assembled, and then tested so that it runs as it should. Bikes being sent to a customer who is unable to collect it from iRIDE, will have it boxed, wheels, saddle and bars generally off and re-packaged.

The delivery of bikes will be organized once a freight fee can be determined based on weight and delivery location.

Assembly should take no longer than 10-20 minutes. It is recommended that a skilled mechanic assemble, or check the bike. If possible your local bike shop is likely best placed to do this from a safety perspective to ensure all is as it should be. If a rider is having any issues we can hook up an online video chat, or talk over the phone. If this service is required email us at workshop@iride.net.nz to organise a time that suits all parties.
